Acura RDX I (2006-2009) left rear turn signal Wiring diagram
This page shows the only wiring diagram for the component.left rear turn signal, which is found in the car Acura RDX I (2006-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left rear turn signal (1 of 1)
BACK-UP SENSOR CONNECTOR
BLK WIRE
DRIVER'S POWER LUMBAR SUPPORT SWITCH
DRIVER'S POWER SEAT ADJUSTMENT SWITCH
DRIVER'S SEAT BELT BUCKLE SWITCH
DRIVER'S SEAT HEATER
DRIVER'S SEAT- BACK HEATER
FRONT PASSENGER'S SEAT BELT BUCKLE SWITCH
FRONT PASSENGER'S SEAT CUSHION HEATER
FRONT PASSENGER'S SEAT HEATER
HIGH MOUNT BRAKE LIGHT
LEFT BACK-UP LIGHT
LEFT BRAKE LIGHT
LEFT INNER TAILLIGHT
LEFT LICENSE PLATE LIGHT
LEFT REAR SIDE MARKER LIGHT
LEFT REAR TURN SIGNAL
LIGHT
ODS UNIT
REAR WINDOW DEFOGGER
REAR WINDOW WIPER MOTOR
RIGHT BACK-UP LIGHT
RIGHT BRAKE LIGHT/ TAILLIGHT
RIGHT INNER TAILLIGHT
RIGHT LICENSE PLATE LIGHT
RIGHT REAR DOOR LOCK ACTUATOR/KNOB SWITCH
RIGHT REAR POWER WINDOW SWITCH
RIGHT REAR SIDE MARKER LIGHT
RIGHT REAR TURN SIGNAL LIGHT
SUBWOOFER
TAILGATE LATCH SWITCH TAILGATE OUTER HANDLE SWITCH
TAILGATE RELEASE ACTUATOR
TAILLIGHT
TECHNOLOGY PACKAGE
TRAILER LIGHTING CONNECTOR
Go to component -> Ground distribution circuit (4 of 4) -> LEFT REAR TURN SIGNAL
