Acura RDX I (2006-2009) left clutch electromagnetic coil Wiring diagram
This page shows the only wiring diagram for the component.left clutch electromagnetic coil, which is found in the car Acura RDX I (2006-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left clutch electromagnetic coil (1 of 1)
AREA NETWORK CONTROLLER
BLK WIRE
BLU WIRE
BLU/YEL WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
FAST CONTROLLER AREA NETWORK TRANSCEIVER
FSR TOH WEN CAN L
FUSE 1
FUSE 10
GAUGE CONTROL MODULE
GRN WIRE
GRN/WHT WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
K LINE
LEFT CLUTCH ELECTROMAGNETIC COIL
LEFT SEARCH COIL
LEFT YOKE SOLENOID
LFH
LT BLU WIRE
LT GRN WIRE
MICU METER
MULTI FUSE 1
ORG/ WIRE
PPL
PPL PWR PG LG-2 LCH LCL RCH RCL
REAR DIFFERENTIAL FLUID TEMPERATURE SENSOR
RED WIRE
RFH
RIGHT CLUTCH ELECTROMAGNETIC COIL
RIGHT SEARCH COIL
RIGHT YOKE SOLENOID
SH-AWD CONTROL UNIT (BEHIND LEFT REAR SIDE TRIM PANEL)
SH-AWD IND
SH-AWD RELAY (BEHIND LEFT REAR SIDE TRIM PANEL)
TOL LG 1 CAN-H LFL RFL
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH)
UNDER-DASH JUNCTION BOX (UNDER LEFT SIDE OF DASH)
UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT)
WARNING DRIVER CIRCUIT
WHT WIRE
YEL WIRE
Go to component -> Rear differential lock circuit -> LEFT CLUTCH ELECTROMAGNETIC COIL
