Acura RDX I (2006-2009) k-line scs scs Wiring diagram
This page shows the only wiring diagram for the component.k-line scs scs, which is found in the car Acura RDX I (2006-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram k-line scs scs (1 of 1)
+B BACKUP K-LINE
5 4 PNK WIRE
BLK WIRE
BRN WIRE
BRN/YEL WIRE
DASH)
DATA LINK CONNECTOR (UNDER LEFT SIDE OF DASH)
FUSE 23
GRN WIRE
HOT AT ALL TIMES
IMMOBILIZER KEYLESS CONTROL UNIT (ON STEERING COLUMN COVER)
K-LINE SCS SCS
LT BLU WIRE
MICU SERVICE CHECK CONNECTOR
ORG/ WIRE
PCM (LEFT FRONT OF ENGINE COMPT)
PNK 4 5 6 7 WIRE
RED WIRE
S GND
SCS WEN SIG HIGH SIG LOW
SH-AWD CONTROL UNIT (BEHIND LEFT REAR SIDE TRIM PANEL)
SIDE OF DASH)
SRS UNIT
STEERING ANGLE SENSOR (IN STEERING COLUMN COVER)
TPMS CONTROL UNIT (UNDER LEFT SIDE OF DASH)
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF MICU MICU CHK
UNDER-DASH JUNCTION BOX (UNDER LEFT
UNDER-DASH JUNCTION BOX (UNDER LEFT SIDE OF DASH)
UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT) FUSE 19
VSA MODULATOR CONTROL UNIT (RIGHT SIDE OF ENGINE COMPT)
WHT WIRE
YAW RATE-LATERAL ACCELERATION SENSOR (UNDER MIDDLE OF DASH) 2 4
YEL WIRE
