Acura RDX I (2006-2009) ini gnd rl ini sig rr ini sig pnk Wiring diagram
This page shows the only wiring diagram for the component.ini gnd rl ini sig rr ini sig pnk, which is found in the car Acura RDX I (2006-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ini gnd rl ini sig rr ini sig pnk (1 of 1)
+B BACK UP
+B TPMS METER METER METER
AREA NETWORK CONTROLLER
AREA)
B-CAN L
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
CONTROLLER
DRIVE CIRCUIT
FAST
FUSE
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
INI GND RL INI SIG RR INI SIG PNK WIRE
LEFT FRONT RIGHT REAR TPMS INITIATOR TPMS INITIATOR (BEHIND LEFT FRONT FENDER)
LEFT REAR TPMS INITIATOR (LEFT REAR WHEELWELL)
LF INI +
LOW TIRE PRESSURE IND
LT BLU WIRE
NETWORK
ORG/ WIRE
PNK WIRE
POWER
RED WIRE
RIGHT FRONT TPMS INITIATOR (BEHIND LEFT FRONT FENDER)
SUPPLY
TPMS CONTROL UNIT (UNDER LEFT SIDE OF DASH)
TPMS IND
TRANSCEIVER/
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH) MICU
UNDER-DASH JUNCTION BOX (UNDER LEFT SIDE OF DASH)
UNDER-HOOD FUSE/RELAY FUSE BOX (LEFT REAR OF ENGINE COMPT)
WARNING
WHT WIRE
Go to component -> Tire pressure monitoring circuit -> INI GND RL INI SIG RR INI SIG PNK WIRE
