Acura RDX I (2006-2009) hip/navi comm 3 Wiring diagram

ACURALINK CONTROL UNIT (XM RECEIVER) (BEHIND GLOVE BOX) AUDIO REMOTE SWITCH AUDIO UNIT B-CAN BLK WIRE BLU WIRE BRN WIRE CABLE REEL COMPUTER DATA LINES SYSTEM GRN WIRE GRN/RED WIRE GRY WIRE HFL-VOICE CONTROL SWITCH HFT ICON HFT MUTE HFT STRG SW HIP/NAVI COMM 1 HIP/NAVI COMM 2 HIP/NAVI COMM 3 HIP/NAVI COMM 4 HIP/NAVI COMM SH ILL INTERFACE DIAL JOG LT BLU WIRE LT GRN WIRE MIC OUT + MIC SH MIC SIG MICROPHONE NAVI GND NAVI L CH NAVI SH GND NAVIGATION SWITCH PANEL OFF HOOK SWITCH ON HOOK SWITCH PNK WIRE PPL PPL BUS - BUS + BUS SH REMOTE GND PPL/ PPL/ PPL/ PTT RED WIRE ROOF CONSOLE SH JOG STEERING WHEEL) STEREO AMPLIFIER (UNDER MIDDLE OF DASH) SUPPLEMENTAL RESTRAINTS SYSTEM TALK SWITCH BACK SWITCH TELM SIG - TELM SIG - TELM SIG + TELM SIG SH HFT MUTE HFT ICON SECURITY TELM SIG SH WHT WIRE YEL WIRE
