Acura RDX I (2006-2009) high mount Wiring diagram
This page shows the only wiring diagram for the component.high mount, which is found in the car Acura RDX I (2006-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram high mount (1 of 1)
+B BACK UP
B-CAN
BLK WIRE
BRAKE LIGHT
BRAKE PEDAL POSITION SWITCH (UNDER LEFT SIDE OF DASH)
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE 12
FUSE 15
FUSE 19
FUSE 23
GRN WIRE
GRY WIRE
HAZ SW
HAZARD WARNING SWITCH
HAZARD WARNING SWITCH LIGHT
HIGH MOUNT
HOT AT ALL TIMES
LEFT BRAKE
LEFT FRONT SIDE MARKER
LEFT FRONT TURN SIGNAL/ PARKING LIGHT
LEFT INNER
LEFT LICENSE
LEFT REAR SIDE
LIGHT
LIGHT/ TAILLIGHT
LT GRN WIRE
MARKER LIGHT
MICU END OF DASH)
ORG/ WIRE
PLATE LIGHT
PNK WIRE
PPL
RED WIRE
RIGHT BRAKE/
RIGHT FRONT SIDE MARKER
RIGHT FRONT TURN SIGNAL/ PARKING LIGHT
RIGHT INNER
RIGHT LICENSE
RIGHT REAR SIDE
S GND
TAILLIGHT
TAILLIGHT RELAY
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT
UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT)
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (1 of 2) -> HIGH MOUNT
