Acura RDX I (2006-2009) front passenger's switch 0) off 1) up Wiring diagram
This page shows the only wiring diagram for the component.front passenger's switch 0) off 1) up, which is found in the car Acura RDX I (2006-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front passenger's switch 0) off 1) up (1 of 1)
2) DOWN 3) AUTO DOWN 4) AUTO UP
AUTO
BLK WIRE
BLU WIRE
CONTROL BLOCK
CONTROL CIRCUIT
DOOR LOCKS SYSTEM
DOWN
DR DOWN
DR UP
FRONT PASSENGER'S DOOR LOCK SWITCH
FRONT PASSENGER'S POWER WINDOW MOTOR (FRONT PASSENGER'S DOOR)
FRONT PASSENGER'S POWER WINDOW SWITCH
FRONT PASSENGER'S SWITCH 0) OFF 1) UP
GRN WIRE
LEFT REAR POWER WINDOW SWITCH
LOCK
LT GRN WIRE
ORG/ WIRE
PLSA
PLSB
PNK WIRE
PPL
PULSER
RED WIRE
RIGHT REAR POWER WINDOW MOTOR (RIGHT REAR DOOR)
RIGHT REAR POWER WINDOW SWITCH
SGND
SVCC
UART
UNLOCK
WHT WIRE
YEL WIRE
Go to component -> Power windows circuit (2 of 2) -> FRONT PASSENGER'S SWITCH 0) OFF 1) UP
