Acura RDX I (2006-2009) drl parking brake check circuit ind Wiring diagram

BLK WIRE BLU WIRE BODY CONTROLLER AREA NETWORK TRANSCEIVER BRN WIRE COMBI GND (LIGHT) COMPUTER FOG LIGHT SWITCH DATA LINES SYSTEM COMBINATION LIGHT SWITCH DAYLIGHT DIMMER/ FLASH-TO-PASS SWITCH PPL DRL PARKING BRAKE CHECK CIRCUIT IND FOG LIGHT RELAY (UNDER LEFT SIDE OF DASH) FR FOG RLY CL- METER FUSE 10 FUSE 12 FUSE 13 FUSE 17 FUSE 16 FUSE 18 FUSE 21 FUSE 37 FUSE 6 GAUGE CONTROL MODULE GRN WIRE GRY WIRE HEAD HEAD OFF HEADLIGHT SWITCH HID UNIT HIGH BEAM HIGH BEAM CONTROL CIRCUIT HIGH BEAM LIGHTS ON FOG LIGHT IND IND IND HOT AT ALL TIMES HOT IN ON HOT IN ON OR START LEFT FOG LIGHT LEFT HEADLIGHT LOW BEAM LOW BEAM HEADLIGHT RELAY LT BLU WIRE METER MICU MULTI INFORMATION DISPLAY (MID) UNIT OFF ORG/ WIRE PARK PARKING BRAKE SWITCH (AT BASE OF PARKING BRAKE LEVER) PASSING PNK 30 WIRE PNK WIRE PPL PPL PPL RED WIRE RIGHT FOG LIGHT RIGHT HEADLIGHT SMALL LT SW H/L OFF SW H/L ON SW DIM SW PASSING SW FOG LT SW +B BACK-UP S-GND UNDER-DASH FUSE/RELAY BOX WHT WIRE YEL WIRE
