Acura RDX I (2006-2009) channel down switch Wiring diagram
This page shows the only wiring diagram for the component.channel down switch, which is found in the car Acura RDX I (2006-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram channel down switch (1 of 1)
+B +B SYS ON BUS SH AUDIO SH AUDIO R+ AUDIO L+
+B BACKUP
AM/FM ANTENNA LEAD CONNECTOR (UNDER RIGHT SIDE OF DASH)
AM/FM/XM ANTENNA (USA) AM/FM ANTENNA (CANADA) (USA: REAR OF ROOF)
ANT +B RF SH RF IN
AUDIO L+
AUDIO R-
AUDIO R- AUDIO L- RF IN RF SH ANT +B
AUDIO REMOTE SWITCH
AUDIO SH
AUDIO UNIT
BLK WIRE
BLU WIRE
BRN WIRE
BUS -
BUS SH
BUS+ BUS- GA-NET GND PPL
CABLE REEL
CHANNEL DOWN SWITCH
CHANNEL UP SWITCH
COMPUTER DATA LINES SYSTEM
FR PRE - SH FR GND
FUSE
FUSE 23 (LEFT REAR OF ENGINE COMPT)
GND (ILL)
GRN WIRE
GRN/RED WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ACC OR ON
ILL
K LINE
LT BLU WIRE
MICU FUSE
MODE SWITCH
NCA WIRE
PCM (LEFT FRONT OF ENGINE COMPT)
PNK WIRE
PPL
RADIO
RED WIRE
SAT/TER
SAT/TER SH
SECURITY
STEERING WHEEL)
SYS ON
UNDER-DASH FUSE/RELAY BOX
UNDER-DASH JUNCTION BOX (UNDER LEFT SIDE OF DASH)
UNDER-HOOD FUSE/RELAY BOX
USA
VOLUME DOWN SWITCH
VOLUME UP SWITCH
VSP PPL
VSSOUT
WHT WIRE
XM RECEIVER (USA)
YEL WIRE
Go to component -> Radio circuit, without technology package (1 of 2) -> CHANNEL DOWN SWITCH
