Acura RDX I (2006-2009) audio unit connector b Wiring diagram
This page shows the only wiring diagram for the component.audio unit connector b, which is found in the car Acura RDX I (2006-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram audio unit connector b (1 of 1)
+B GA-NET 2
ACC POWER
AUD L+
AUD R+
AUDIO UNIT CONNECTOR B
BLK WIRE
BLU WIRE
BRAIDED WIRE
BRN WIRE
BRN/BLK WIRE
BUS -
DOCK RX
DOCK TX
F/W POWER
GA-NET SYSTEM ACC
GRN WIRE
MUSIC LINK CONNECTOR
MUSIC LINK UNIT
ORG/ WIRE
ORG/BLK WIRE
RED WIRE
RED/BLK WIRE
SHIELDED WIRE
SHIELDED WIRE AUDIO GND
SHIELDED WIRE SHIELDED WIRE
WHT WIRE
YEL WIRE
Go to component -> Music link circuit, accessory -> AUDIO UNIT CONNECTOR B
