Acura RDX I (2006-2009) area network fast controller Wiring diagram
This page shows the only wiring diagram for the component.area network fast controller, which is found in the car Acura RDX I (2006-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram area network fast controller (1 of 1)
AREA NETWORK FAST CONTROLLER
BLK WIRE
BRAKE PEDAL POSITION SWITCH (UNDER LEFT SIDE OF DASH)
BRN WIRE
CABLE REEL
CANCEL SWITCH
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL
CRUISE CONTROL COMBINATION SWITCH
CRUISE CONTROL DIMMING CIRCUIT
CRUISE CONTROL IND
FUSE
FUSE 10
GAUGE CONTROL MODULE
GRN/ LT WIRE
GRN/RED WIRE
GRY WIRE
HORN SWITCH
HOT IN ON OR START
LT BLU WIRE
LT GRN WIRE
MAIN SWITCH
MAIN SWITCH IND
MICU
MICU METER
NCA WIRE
ORG/ WIRE
RED WIRE
RESUME + SWITCH
SET SWITCH
STEERING WHEEL)
TRANSCEIVER/
TRANSMISSIONS SYSTEM
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH)
WARNING DRIVER CIRCUIT
WHT WIRE
YEL WIRE
Go to component -> Cruise control circuit (2 of 2) -> AREA NETWORK FAST CONTROLLER
