Acura MDX IV (2021-2024) wip int wip on off wash Wiring diagram
This page shows the only wiring diagram for the component.wip int wip on off wash, which is found in the car Acura MDX IV (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram wip int wip on off wash (1 of 1)
BLK WIRE
BLU WIRE
BODY CONTROL MODULE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DIODE A
DIODE B
DRIVER'S JUNCTION BOX B
FUSE 11
FUSE 29
FUSE 31
FUSE 5
FUSE HOLDER A
GRN WIRE
HOT AT ALL TIMES
HOT W/
LT BLU WIRE
LT GRN WIRE
PPL
REAR WINDOW WASHER MOTOR RELAY
REAR WINDOW WIPER MOTOR
RED WIRE
RELAY CIRCUIT BOARD
RELAY CONTROL MODULE
RELAY ENERGIZED
REVERSE RELAY
TRANSMISSION CONTROL MODULE
TYPE-A
TYPE-B
UNDER-DASH FUSE/RELAY BOX
UNDER-HOOD FUSE/RELAY BOX
WASH
WASH WASH
WHT WIRE
WINDSHIELD WASHER MOTOR RELAY
WINDSHIELD/ REAR WINDOW WASHER MOTOR
WIP INT WIP ON OFF
WIP INT WIP ON OFF WASH
WIPER/WASHER SWITCH
YEL WIRE
Go to component -> Rear wiper/washer circuit -> WIP INT WIP ON OFF WASH
