Acura MDX IV (2021-2024) top of transmission) Wiring diagram
This page shows the only wiring diagram for the component.top of transmission), which is found in the car Acura MDX IV (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram top of transmission) (1 of 1)
ACC COMBINATION SWITCH
ATF TEMPERATURE SENSOR
AUDIO REMOTE- HFL SWITCH
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
CABLE REEL
CLUTCH PRESSURE CONTROL SOLENOID VALVE A
CLUTCH PRESSURE CONTROL SOLENOID VALVE F
COMPUTER DATA LINES SYSTEM
GRN WIRE
GRN/BLK WIRE
GRY WIRE
LT BLU WIRE
LT GRN WIRE
PADDLE SHIFTER + (UPSHIFT SWITCH)
PADDLE SHIFTER - (DOWNSHIFT SWITCH)
PPL
RED WIRE
STEERING COLUMN)
TOP OF TRANSMISSION)
TRANSMISSION FLUID PRESSURE SENSOR A
TRANSMISSION FLUID PRESSURE SENSOR F
TWO-WAY CLUTCH ACTUATOR VALVE STROKE SENSOR
WHT WIRE
YEL WIRE
Go to component -> A/t circuit (2 of 3) -> TOP OF TRANSMISSION)
