Acura MDX IV (2021-2024) second row seat heater switches Wiring diagrams
This page contains all the electrical diagrams for the component. second row seat heater switches, in which he is found in the car Acura MDX IV (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
second row seat heater switches wiring diagram (1 of 2)
3.0L TURBO
3.5L
A/C CONDENSER FAN MOTOR
BLK WIRE
BLU WIRE
BRN WIRE
CLIMATE CONTROL UNIT (LOWER RIGHT SIDE OF HVAC BLOWER HOUSING)
FRONT SEAT HEATER SWITCH INDICATORS (LEDS)
FRONT SEAT HEATER SWITCHES
FUSE 16
FUSE 2-4
FUSE 20
FUSE 3-3
FUSE 3-4
FUSE 38
FUSE 4-3
FUSE 6
FUSE HOLDER A
FUSE/RELAY HOLDER C
FUSE/RELAY HOLDER D
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ PGM-FI MAIN RELAY 1 ENERGIZED
LT BLU WIRE
LT GRN WIRE
PNK WIRE
PPL
RADIATOR FAN MOTOR
REAR CLIMATE CONTROL PANEL
RED WIRE
RELAY CIRCUIT BOARD
SEATS SYSTEM
SECOND ROW SEAT HEATER INDICATORS (LEDS)
SECOND ROW SEAT HEATER SWITCHES
TAN WIRE
UNDER-HOOD FUSE/RELAY BOX
WHT WIRE
YEL WIRE
Go to component -> Automatic a/c circuit (3 of 5) -> SECOND ROW SEAT HEATER SWITCHES
second row seat heater switches wiring diagram (2 of 2)
BLK WIRE
BLK/RED WIRE
BLU WIRE
BREAKER
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE 43
FUSE 7
FUSE C
FUSE/RELAY HOLDER A
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ DC-DC
LEFT SECOND ROW SEAT BACK HEATER
LEFT SECOND ROW SEAT CUSHION HEATER
LT BLU WIRE
PNK WIRE
POWER DISTRIBUTION MODULE
PPL
REAR CLIMATE CONTROL PANEL
RED WIRE
RELAY 2 ENERGIZED
RELAY ENERGIZED
RIGHT SECOND ROW SEAT BACK HEATER
RIGHT SECOND ROW SEAT CUSHION HEATER
SECOND ROW SEAT HEATER CONTROL UNIT
SECOND ROW SEAT HEATER SWITCH IND (LEDS)
SECOND ROW SEAT HEATER SWITCHES
SMART FET
THERMISTOR
UNDER-DASH FUSE/RELAY BOX
WHT WIRE
YEL WIRE
Go to component -> Rear heated seats circuit -> SECOND ROW SEAT HEATER SWITCHES
