Acura MDX IV (2021-2024) right rear door courtesy unit Wiring diagram
This page shows the only wiring diagram for the component.right rear door courtesy unit, which is found in the car Acura MDX IV (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right rear door courtesy unit (1 of 1)
3.0L TURBO
3.5L
BLK WIRE
BLU WIRE
CONSOLE BOX LIGHT
ENTRY LIGHT TIMER CIRCUIT
FULL LATCH SWITCH
GLOVE BOX LIGHT
GRN WIRE
LEFT CONSOLE BOX LIGHT
LEFT TAILGATE LIGHT
LT GRN WIRE
PNK WIRE
POWER TAILGATE CLOSER UNIT
POWER TAILGATE CONTROL UNIT
POWER TAILGATE INSIDE SWITCH
PPL
RED WIRE
RIGHT CONSOLE BOX LIGHT
RIGHT END OF DASH)
RIGHT REAR DOOR COURTESY UNIT
RIGHT REAR DOOR INNER HANDLE LIGHT
RIGHT REAR DOOR LATCH
RIGHT REAR DOOR LOWER AMBIENT LIGHT
RIGHT REAR DOOR POCKET LIGHT
RIGHT REAR DOOR UPPER AMBIENT LIGHT
RIGHT REAR POWER WINDOW SWITCH
RIGHT TAILGATE LIGHT
TAN WIRE
WHT WIRE
YEL WIRE
Go to component -> Courtesy lamps circuit (4 of 5) -> RIGHT REAR DOOR COURTESY UNIT
