Acura MDX IV (2021-2024) right rear corner sensor Wiring diagram
This page shows the only wiring diagram for the component.right rear corner sensor, which is found in the car Acura MDX IV (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right rear corner sensor (1 of 1)
3.0L TURBO
3.5L
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S CENTER JUNCTION BOX B
FUSE CB
FUSE/ RELAY HOLDER A
GRN WIRE
GRY WIRE
HOT W/ DC-DC
LEFT REAR CENTER SENSOR
LEFT REAR CORNER SENSOR
LT BLU WIRE
LT GRN WIRE
PARKING, BACKUP SENSOR CONTROL UNIT
PNK WIRE
PPL
RED WIRE
RIGHT REAR CENTER SENSOR
RIGHT REAR CORNER SENSOR
WHT WIRE
YEL WIRE
Go to component -> Parking assistant circuit (1 of 2) -> RIGHT REAR CORNER SENSOR
