Acura MDX IV (2021-2024) rear window washer motor relay Wiring diagrams
This page contains all the electrical diagrams for the component. rear window washer motor relay, in which he is found in the car Acura MDX IV (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram rear window washer motor relay (1 of 3)
AUTOMATIC LIGHTING CONTROL UNIT-SENSOR
AUTOMATIC LIGHTING/RAIN SENSOR
B-CAN H
B-CAN L
B-CAN TRANSCEIVER
BLK WIRE
BLU WIRE
BODY CONTROL MODULE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S CENTER JUNCTION BOX A
DRIVER'S JUNCTION BOX A
FUSE 20
FUSE 29
FUSE 31
FUSE 7
FUSE F
FUSE HOLDER A
FUSE/ RELAY HOLDER A
GAUGE CONTROL MODULE (REAR OF INSTRUMENT CLUSTER)
GRN WIRE
HOT AT ALL TIMES
HOT W/
HOT W/ DC-DC CONVERTER
INT LO OFF
INT OFF LO HI MIST
INTERMITTENT DWELL TIME CONTROLLER
LT BLU WIRE
LT GRN WIRE
OFF
PASSENGER'S CENTER JUNCTION BOX D
PPL
REAR WINDOW WASHER MOTOR RELAY
RED WIRE
RELAY CIRCUIT BOARD
RELAY CONTROL MODULE
TRANSMISSION CONTROL MODULE
TYPE-A
TYPE-B
UNDER-DASH FUSE/RELAY BOX
UNDER-HOOD FUSE/RELAY BOX
WASH
WASHER FLUID LEVEL SWITCH
WASHER SWITCH
WHT WIRE
WINDSHIELD WASHER MOTOR RELAY
WINDSHIELD WIPER CONTROL UNIT/MOTOR
WINDSHIELD WIPER SWITCH
WINDSHIELD/REAR WINDOW WASHER MOTOR
WIPER/WASHER SWITCH
YEL WIRE
Go to component -> Front wiper/washer circuit -> REAR WINDOW WASHER MOTOR RELAY
Wiring diagram rear window washer motor relay (2 of 3)
3.0L TURBO
3.0L TURBO, 3.5L
3.5L
3.5L 3.0L TURBO
BLK WIRE
BLU WIRE
BODY CONTROL MODULE
BRAKE LIGHT RELAY
BRAKE PEDAL POSITION SWITCH
CONTROL UNIT)
ELECTRIC BRAKE BOOSTER
FROM FUSE 5-7 (DIAGRAM 1 OF 12)
FUSE 21
FUSE 23
FUSE 25
FUSE 26
FUSE 27
FUSE 28
FUSE 31
FUSE 4-2
FUSE 4-4
FUSE 5
FUSE 5-1
FUSE 5-2
FUSE 5-4
FUSE 5-5
FUSE 6
FUSE 7
FUSE HOLDER A
GRY WIRE
PNK WIRE
POWER DISTRIBUTION MODULE (RIGHT KICK PANEL)
PPL
REAR WINDOW WASHER MOTOR RELAY
RED WIRE
RELAY CIRCUIT BOARD
RELAY CONTROL MODULE
REVERSE BATTERY PROTECTION
SMART FET
TRANSMISSION CONTROL MODULE
UNDER-HOOD FUSE/RELAY BOX
VSA MODULATOR CONTROL UNIT
WHT WIRE
WINDSHIELD WASHER MOTOR RELAY
WINDSHIELD WIPER CONTROL UNIT/MOTOR
YEL WIRE
Go to component -> Power distribution circuit (2 of 12) -> REAR WINDOW WASHER MOTOR RELAY
Wiring diagram rear window washer motor relay (3 of 3)
