Acura MDX IV (2021-2024) rear bumper lf antenna Wiring diagrams
This page contains all the electrical diagrams for the component. rear bumper lf antenna, in which he is found in the car Acura MDX IV (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram rear bumper lf antenna (1 of 2)
3.0L TURBO
3.5L
BLK WIRE
BLU WIRE
BODY CONTROL MODULE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S CENTER JUNCTION BOX A
ELECTRIC BRAKE BOOSTER
ELECTRIC SERVO BRAKE CONTROL UNIT/ PEDAL FEEL SIMULATOR
FRONT INTERIOR LF ANTENNA
FUSE 23
FUSE HOLDER A
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LEFT REAR LF ANTENNA/INITIATOR
LT BLU WIRE
LT GRN WIRE
MIDDLE INTERIOR LF ANTENNA
PNK WIRE
PPL
REAR BUMPER LF ANTENNA
REAR INTERIOR LF ANTENNA
RED WIRE
RIGHT REAR LF ANTENNA/INITIATOR
TAN WIRE
TRANSMISSION CONTROL MODULE (TCM)
UNDER-HOOD FUSE/RELAY BOX
WHT WIRE
YEL WIRE
Go to component -> Anti-theft circuit (1 of 6) -> REAR BUMPER LF ANTENNA
