Acura MDX IV (2021-2024) low tire pressure/tpms ind Wiring diagram
This page shows the only wiring diagram for the component.low tire pressure/tpms ind, which is found in the car Acura MDX IV (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram low tire pressure/tpms ind (1 of 1)
ABS IND.
AUTOMATIC BRAKE HOLD IND
B-CAN H
B-CAN L
B-CAN TRANSCEIVER
BLK WIRE
BLU WIRE
BRAKE HOLD SWITCH
BRAKE SYSTEM IND (AMBER)
BRAKE SYSTEM IND (RED) WIRE
BRN WIRE
BUZZER
CHARGING SYSTEM IND
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL SYSTEM
DOOR, TAILGATE OPEN IND
DRIVER'S JUNCTION BOX B
EPS IND
F-CAN H
F-CAN L
F-CAN TRANSCEIVER
FRONT FOG LIGHT IND
FUSE A
FUSE/RELAY HOLDER A
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HEAD-UP DISPLAY CIRCUIT
HIGH BEAM IND
HOT W/ DC-DC CONVERTER
IDLE STOP OFF SWITCH
IDLE STOP OFF/AUTOMATIC BRAKE HOLD SWITCH
ILLUM
INTEGRATED DYNAMICS SYSTEM SWITCH
KEYLESS ACCESS IND
LEFT TURN SIGNAL IND
LIGHTS ON IND
LOW TIRE PRESSURE/TPMS IND
LT BLU WIRE
LT GRN WIRE
MALFUNCTION IND LAMP (MIL)
MOST
MULTI VISOR SWITCH
MULTI-INFORMATION DISPLAY (MID)
NCA WIRE
PNK WIRE
PPL
RED WIRE
RIGHT TURN SIGNAL IND
SAFETY SUPPORT
SEAT BELT REMINDER IND
SECURITY IND
SOUND SYSTEMS
SRS IND
TAN WIRE
TRANSCEIVER/
VSA IND
VSA OFF
VSA OFF IND
WHT WIRE
WIPER/WASHER SYSTEM
YEL WIRE
Go to component -> Instrument cluster circuit (1 of 3) -> LOW TIRE PRESSURE/TPMS IND
