Acura MDX IV (2021-2024) left satellite speaker Wiring diagrams
This page contains all the electrical diagrams for the component. left satellite speaker, in which he is found in the car Acura MDX IV (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left satellite speaker (1 of 2)
ASSIST SWITCH
AUDIO REMOTE- HFL SWITCH
B-CAN
B-CAN H
B-CAN L
BLK WIRE
BLU WIRE
BRN WIRE
CABLE REEL
COMPUTER DATA LINES SYSTEM
DRIVER'S JUNCTION BOX B
FUSE 5
FUSE/ RELAY HOLDER B
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LEFT SATELLITE SPEAKER
LINK SWITCH
LT BLU WIRE
LT GRN WIRE
MOST I/F
NCA WIRE
PNK WIRE
PPL
RED WIRE
RIGHT SATELLITE SPEAKER
RIGHT SECOND ROW ROOF SPEAKER
STEERING COLUMN)
STEREO AMPLIFIER (BEHIND RIGHT REAR SIDE TRIM PANEL)
SYSTEM STATUS INDICATOR (LED)
TAN WIRE
TRANSCEIVER/
TUNER UNIT (BEHIND RIGHT REAR SIDE TRIM PANEL)
WHT WIRE
YEL WIRE
Go to component -> Navigation circuit, 16 speakers (4 of 5) -> LEFT SATELLITE SPEAKER
Wiring diagram left satellite speaker (2 of 2)
ASSIST SWITCH
AUDIO REMOTE- HFL SWITCH
B-CAN
B-CAN H
B-CAN L
BLK WIRE
BLU WIRE
BRN WIRE
CABLE REEL
COMPUTER DATA LINES SYSTEM
DRIVER'S JUNCTION BOX B
FUSE 5
FUSE/ RELAY HOLDER B
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LEFT SATELLITE SPEAKER
LINK SWITCH
LT BLU WIRE
LT GRN WIRE
MOST I/F
NCA WIRE
PNK WIRE
PPL
RED WIRE
RIGHT SATELLITE SPEAKER
RIGHT SECOND ROW ROOF SPEAKER
STEERING COLUMN)
STEREO AMPLIFIER (BEHIND RIGHT REAR SIDE TRIM PANEL)
SYSTEM STATUS INDICATOR (LED)
TAN WIRE
TRANSCEIVER/
TUNER UNIT (BEHIND RIGHT REAR SIDE TRIM PANEL)
WHT WIRE
YEL WIRE
Go to component -> Radio circuit, 16 speakers (4 of 5) -> LEFT SATELLITE SPEAKER
