Acura MDX IV (2021-2024) left rear door upper ambient light Wiring diagrams
This page contains all the electrical diagrams for the component. left rear door upper ambient light, in which he is found in the car Acura MDX IV (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left rear door upper ambient light (1 of 4)
3.0L TURBO
3.5L
BLU WIRE
DRIVER'S DOOR LOWER AMBIENT LIGHT
DRIVER'S DOOR UPPER AMBIENT LIGHT
DRIVER'S POWER SEAT CONTROL UNIT
FRONT PASSENGER'S DOOR INNER HANDLE LIGHT
FRONT PASSENGER'S POWER SEAT CONTROL UNIT
FRONT SEAT HEATER CONTROL UNIT/VENTILATED SEAT CONTROL UNIT
GRN WIRE
LEFT REAR DOOR INNER HANDLE LIGHT
LEFT REAR DOOR LOWER AMBIENT LIGHT
LEFT REAR DOOR POCKET LIGHT
LEFT REAR DOOR UPPER AMBIENT LIGHT
LEFT SIDE BSI RADAR UNIT
LT GRN WIRE
PNK WIRE
POWER TAILGATE CONTROL UNIT
RED WIRE
RIGHT REAR DOOR INNER HANDLE LIGHT
RIGHT REAR DOOR UPPER AMBIENT LIGHT
TAN WIRE
WHT WIRE
YEL WIRE
Go to component -> Computer data lines circuit (8 of 8) -> LEFT REAR DOOR UPPER AMBIENT LIGHT
Wiring diagram left rear door upper ambient light (2 of 4)
3.0L TURBO
3.0L TURBO, 3.5L
3.5L
BLK WIRE
BLU WIRE
BRN WIRE
CENTER INSTRUMENT PANEL AMBIENT LIGHT
FRONT PASSENGER'S DOOR CONTROL UNIT
FRONT PASSENGER'S DOOR COURTESY LIGHT
FRONT PASSENGER'S DOOR INNER HANDLE LIGHT
FRONT PASSENGER'S DOOR LOWER AMBIENT LIGHT
FRONT PASSENGER'S DOOR POCKET LIGHT
FRONT PASSENGER'S DOOR UPPER AMBIENT LIGHT
GRN WIRE
LEFT REAR DOOR INNER HANDLE LIGHT
LEFT REAR DOOR LATCH
LEFT REAR DOOR LOWER AMBIENT LIGHT
LEFT REAR DOOR POCKET LIGHT
LEFT REAR DOOR UPPER AMBIENT LIGHT
LT BLU WIRE
LT GRN WIRE
PANORAMIC GLASS ROOF MOTOR-CONTROL UNIT
PASSENGER'S INSTRUMENT PANEL AMBIENT LIGHT
PNK WIRE
PPL
RED WIRE
RIGHT END OF DASH)
RIGHT REAR DOOR CONTROL UNIT
TAN WIRE
WHT WIRE
YEL WIRE
Go to component -> Courtesy lamps circuit (3 of 5) -> LEFT REAR DOOR UPPER AMBIENT LIGHT
Wiring diagram left rear door upper ambient light (3 of 4)
BLK WIRE
BRN WIRE
DRIVER'S BACK SEAT BLOWER MOTOR
DRIVER'S BACK SEAT HEATER
DRIVER'S POWER SEAT CONTROL UNIT
DRIVER'S SEAT BELT BUCKLE SWITCH
DRIVER'S SEAT CUSHION BLOWER MOTOR
DRIVER'S SEAT CUSHION HEATER
DRIVER'S SEAT HEIGHT MOTOR
DRIVER'S SEAT LEFT BOLSTER MOTOR
DRIVER'S SEAT POWER LUMBAR SUPPORT MOTOR A
DRIVER'S SEAT POWER LUMBAR SUPPORT MOTOR B
DRIVER'S SEAT POWER THIGH SUPPORT MOTOR
DRIVER'S SEAT RECLINE MOTOR
DRIVER'S SEAT RIGHT BOLSTER MOTOR
DRIVER'S SEAT SLIDE MOTOR
DRIVER'S SEAT TILT MOTOR
ELECTRONIC AIR SUSPENSION CONTROL UNIT
EPS CONTROL UNIT
FRONT PASSENGER'S POWER SEAT CONTROL UNIT
FRONT PASSENGER'S SEAT HEIGHT MOTOR
FRONT PASSENGER'S SEAT LEFT BOLSTER MOTOR
FRONT PASSENGER'S SEAT POWER LUMBAR SUPPORT MOTOR A
FRONT PASSENGER'S SEAT POWER LUMBAR SUPPORT MOTOR B
FRONT PASSENGER'S SEAT POWER THIGH SUPPORT MOTOR
FRONT PASSENGER'S SEAT RECLINE MOTOR
FRONT PASSENGER'S SEAT RIGHT BOLSTER MOTOR
FRONT PASSENGER'S SEAT SLIDE MOTOR
FRONT PASSENGER'S SEAT TILT MOTOR
FRONT SEAT HEATER CONTROL UNIT
FRONT SEAT HEATER CONTROL UNIT/VENTILATED SEAT CONTROL UNIT
FUEL TANK UNIT
LEFT REAR DOOR COURTESY LIGHT
LEFT REAR DOOR INNER HANDLE LIGHT
LEFT REAR DOOR LATCH
LEFT REAR DOOR LOWER AMBIENT LIGHT
LEFT REAR DOOR OUTER HANDLE
LEFT REAR DOOR POCKET LIGHT
LEFT REAR DOOR UPPER AMBIENT LIGHT
Go to component -> Ground distribution circuit (3 of 6) -> LEFT REAR DOOR UPPER AMBIENT LIGHT
Wiring diagram left rear door upper ambient light (4 of 4)
CENTER INSTRUMENT PANEL AMBIENT LIGHT
DRIVER'S DOOR INNER HANDLE LIGHT
DRIVER'S DOOR LOWER AMBIENT LIGHT
DRIVER'S DOOR POCKET LIGHT
DRIVER'S DOOR UPPER AMBIENT LIGHT
DRIVER'S FOOTWELL LIGHT
DRIVER'S INSTRUMENT PANEL AMBIENT LIGHT
FROM FUSE 22 (DIAGRAM 5 OF 12)
FRONT PASSENGER'S DOOR INNER HANDLE LIGHT
FRONT PASSENGER'S DOOR LOWER AMBIENT LIGHT
FRONT PASSENGER'S DOOR POCKET LIGHT
FRONT PASSENGER'S DOOR UPPER AMBIENT LIGHT
FRONT PASSENGER'S FOOTWELL LIGHT
FRONT PASSENGER'S INSTRUMENT PANEL AMBIENT LIGHT
FUSE 16
FUSE 20
FUSE 25
FUSE 26
LEFT CONSOLE BOX LIGHT
LEFT REAR DOOR INNER HANDLE LIGHT
LEFT REAR DOOR LOWER AMBIENT LIGHT
LEFT REAR DOOR POCKET LIGHT
LEFT REAR DOOR UPPER AMBIENT LIGHT
PANORAMIC GLASS ROOF MOTOR-CONTROL UNIT
PNK WIRE
PPL
RIGHT CONSOLE BOX LIGHT
RIGHT REAR DOOR INNER HANDLE LIGHT
RIGHT REAR DOOR LOWER AMBIENT LIGHT
RIGHT REAR DOOR POCKET LIGHT
RIGHT REAR DOOR UPPER AMBIENT LIGHT
SBW SHIFTER CONTROL MODULE
SRS UNIT
WHT WIRE
Go to component -> Power distribution circuit (7 of 12) -> LEFT REAR DOOR UPPER AMBIENT LIGHT
