Acura MDX IV (2021-2024) idle stop off/ automatic brake hold switch Wiring diagrams
This page contains all the electrical diagrams for the component. idle stop off/ automatic brake hold switch, in which he is found in the car Acura MDX IV (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram idle stop off/ automatic brake hold switch (1 of 2)
3.0L TURBO
3.5L
BLK WIRE
BLU WIRE
BRAKE HOLD SWITCH
BRAKE PEDAL POSITION SWITCH
BRAKE SYSTEM IND (AMBER)
BRAKE SYSTEM IND (RED) WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DISPLAY
DRIVER'S J/B A
F-CAN
F-CAN H
F-CAN L
FUSE 20
FUSE 25
FUSE HOLDER A
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
IDLE STOP OFF/ AUTOMATIC BRAKE HOLD SWITCH
LT GRN WIRE
MULTI-INFORMATION
PCM
PNK WIRE
TRANSCEIVER/
UNDER-HOOD FUSE/RELAY BOX
YEL WIRE
Go to component -> Electric servo brake system circuit (2 of 2) -> IDLE STOP OFF/ AUTOMATIC BRAKE HOLD SWITCH
Wiring diagram idle stop off/ automatic brake hold switch (2 of 2)
BLK WIRE
BRN WIRE
DRIVER'S FOOTWELL LIGHT
FRONT AMBIENT LIGHT
FRONT PASSENGER'S FOOTWELL LIGHT
IDLE STOP OFF/ AUTOMATIC BRAKE HOLD SWITCH
INTEGRATED DYNAMICS SYSTEM SWITCH
LEFT REAR INDIVIDUAL MAP LIGHT
LIGHT
MULTI VISOR SWITCH
PPL
REAR AMBIENT LIGHT
REAR CLIMATE CONTROL PANEL
REAR VIEW MIRROR)
RED WIRE
SBW SHIFTER CONTROL MODULE
TOUCHPAD UNIT
USB CHARGER UNIT (FRONT CONSOLE)
USB CHARGER UNIT (REAR CONSOLE)
USB PORT HOLDER
USB PORT LIGHT
VOLUME, SEEK SWITCH
Go to component -> Instrument illumination circuit (2 of 3) -> IDLE STOP OFF/ AUTOMATIC BRAKE HOLD SWITCH
