Acura MDX IV (2021-2024) hot w/ dc-dc converter relay energized Wiring diagram
This page shows the only wiring diagram for the component.hot w/ dc-dc converter relay energized, which is found in the car Acura MDX IV (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hot w/ dc-dc converter relay energized (1 of 1)
3.0L TURBO
3.5L
ACC COMBINATION SWITCH
AUDIO REMOTE- HFL SWITCH
BLK WIRE
BLU WIRE
BRAKE LIGHT RELAY
BRAKE PEDAL POSITION SWITCH
BRN WIRE
CABLE REEL
CANCEL SWITCH
COMPUTER DATA LINES SYSTEM
DISTANCE SWITCH
F-CAN
F-CAN H
F-CAN L
FUSE 25
FUSE CB
FUSE F
FUSE HOLDER A
FUSE/ RELAY HOLDER A
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ DC-DC CONVERTER
HOT W/ DC-DC CONVERTER RELAY ENERGIZED
LKAS SWITCH
LT BLU WIRE
LT GRN WIRE
MAIN SWITCH
PASSENGER'S CENTER JUNCTION BOX D
PNK WIRE
PPL
RED WIRE
RELAY CIRCUIT BOARD
RES/+ SWITCH
SET SWITCH
STEERING COLUMN)
TRANSCEIVER/
UNDER- HOOD FUSE/ RELAY BOX
VSA MODULATOR CONTROL UNIT
WHT WIRE
YEL WIRE
Go to component -> Cruise control circuit (3 of 3) -> HOT W/ DC-DC CONVERTER RELAY ENERGIZED
