Acura MDX IV (2021-2024) heated steering wheel control unit Wiring diagrams
This page contains all the electrical diagrams for the component. heated steering wheel control unit, in which he is found in the car Acura MDX IV (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram heated steering wheel control unit (1 of 3)
12 VOLT BATTERY SENSOR
3.0L TURBO
3.5L
3.5L AWD, 3.0L TURBO
AUDIO REMOTE- HFL SWITCH
BLU WIRE
BRN WIRE
CABLE REEL
DRIVER'S JUNCTION BOX B
ELECTRIC BRAKE BOOSTER
ELECTRIC SERVO BRAKE CONTROL UNIT/PEDAL FEEL SIMULATOR
ELECTRONIC AIR SUSPENSION CONTROL UNIT
GRN WIRE
HEATED STEERING WHEEL CONTROL UNIT
PNK WIRE
PPL
REAR DIFFERENTIAL PUMP MOTOR
RED WIRE
SRS UNIT (UNDER FRONT OF CENTER CONSOLE)
STEERING COLUMN)
VSA MODULATOR CONTROL UNIT
WHT WIRE
YEL WIRE
Go to component -> Computer data lines circuit (5 of 8) -> HEATED STEERING WHEEL CONTROL UNIT
Wiring diagram heated steering wheel control unit (2 of 3)
12 VOLT BATTERY SENSOR
AUTOMATIC LIGHTING/ RAIN SENSOR
BLK WIRE
BODY CONTROL MODULE
CARGO AREA ACCESSORY POWER SOCKET RELAY
DATA LINK CONNECTOR (DLC)
DC-DC CONVERTER ACC RELAY 1
DRIVER'S DOOR CONTROL UNIT
DRIVER'S DOOR COURTESY LIGHT
DRIVER'S DOOR INNER HANDLE LIGHT
DRIVER'S DOOR LATCH
DRIVER'S DOOR LOWER AMBIENT LIGHT
DRIVER'S DOOR OUTER HANDLE
DRIVER'S DOOR POCKET LIGHT
DRIVER'S DOOR UPPER AMBIENT LIGHT
DRIVER'S POWER TAILGATE SWITCH
DRIVER'S VANITY MIRROR LIGHT
DRIVING POSITION MEMORY SWITCH
ELECTRIC PARKING BRAKE SWITCH
FRONT CONSOLE ACCESSORY POWER SOCKET RELAY
FUEL PUMP CONTROL MODULE
FUEL PUMP DRIVER UNIT
FUSE/RELAY HOLDER A
FUSE/RELAY HOLDER E
HEATED STEERING WHEEL CONTROL UNIT
HIGH MOUNT BRAKE LIGHT
LEFT INNER TAILLIGHT
LEFT POWER MIRROR
LEFT REAR DOOR CONTROL UNIT
LICENSE PLATE LIGHT
MULTI VISOR SWITCH
MULTIPURPOSE CAMERA UNIT
PANORAMIC GLASS ROOF MOTOR-CONTROL UNIT
PASSENGER'S VANITY MIRROR LIGHT
POWER DOOR LOCK RELAY (DR UNLOCK)
POWER DOOR LOCK RELAY (LOCK)
POWER DOOR LOCK RELAY (UNLOCK)
POWER SUNSHADE MOTOR- CONTROL UNIT
POWER TAILGATE CONTROL UNIT
REAR VIEW MIRROR)
REAR WINDOW DEFOGGER
REAR WINDOW WIPER MOTOR
RIGHT INNER TAILLIGHT
ROOF MODULE)
UNDER-HOOD FUSE/RELAY BOX
USB CHARGING UNIT (LEFT THIRD ROW)
Go to component -> Ground distribution circuit (1 of 6) -> HEATED STEERING WHEEL CONTROL UNIT
Wiring diagram heated steering wheel control unit (3 of 3)
AUDIO REMOTE- HFL SWITCH
BLK WIRE
BLU WIRE
BRN WIRE
CABLE REEL (STEERING COLUMN)
DRIVER'S JUNCTION BOX B
FUSE 3
GRN WIRE
GRY WIRE
HEATED STEERING WHEEL CONTROL UNIT
HEATED STEERING WHEEL SWITCH
HOT AT ALL TIMES
INDICATOR
LIN TRANSCEIVER
LT BLU WIRE
PNK PPL WIRE
PNK WIRE
POWER DISTRIBUTION MODULE
PPL
RED WIRE
SMART FET
STEERING HEATER/ TEMPERATURE SENSOR
STEERING WHEEL)
TAN WIRE
WHT WIRE
YEL WIRE
Go to component -> Heated steering wheel circuit -> HEATED STEERING WHEEL CONTROL UNIT
