Acura MDX IV (2021-2024) handsfree access power tailgate close switch wiring diagram
This page shows the only wiring diagram for the component.handsfree access power tailgate close switch, which is found in the car Acura MDX IV (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
handsfree access power tailgate close switch wiring diagram (1 of 1)
3.0L TURBO
3.0L TURBO, 3.5L
3.5L
3.5L 3.0L TURBO
3.5L 3.5L
BLK WIRE
BLU WIRE
BRN WIRE
CARGO AREA ACCESSORY POWER SOCKET
CKP SENSOR
CMP SENSOR
EGR VALVE
FUEL CONTROL SOLENOID SHIELD
GRN WIRE
GRY WIRE
HANDSFREE ACCESS POWER TAILGATE CLOSE SWITCH
HANDSFREE ACCESS POWER TAILGATE CONTROL UNIT/ SENSOR
IGNITION COIL 1
IGNITION COIL 2
IGNITION COIL 3
IGNITION COIL 4
IGNITION COIL 5
IGNITION COIL 6
INJECTOR 1 SHIELD
INJECTOR 2 SHIELD
INJECTOR 3 SHIELD
INJECTOR 4 SHIELD
INJECTOR 5 SHIELD
INJECTOR 6 SHIELD
KEYLESS BUZZER
KNOCK SENSOR 1 (BANK 1) SHIELD
KNOCK SENSOR 2 (BANK 2) SHIELD
LEFT SIDE BSI RADAR UNIT
LEFT TAILLIGHT
REAR LIGHT JUNCTION UNIT
ROCKER AIM OIL CONTROL SOLENOID A (BANK 1)
ROCKER AIM OIL CONTROL SOLENOID A (BANK 2)
ROCKER AIM OIL CONTROL SOLENOID B (BANK 1)
ROCKER AIM OIL PRESSURE SWITCH A (BANK 1)
ROCKER AIM OIL PRESSURE SWITCH A (BANK 2)
ROCKER ARM OIL CONTROL SOLENOID
THERMAL JOINT 1
THERMAL JOINT 2
VTC OIL CONTROL SOLENOID VALVE A (BANK 1)
VTC OIL CONTROL SOLENOID VALVE A (BANK 2)
VTC OIL CONTROL SOLENOID VALVE B (BANK 1)
VTC OIL CONTROL SOLENOID VALVE B (BANK 2)
WHT WIRE
YEL WIRE
Go to component -> Ground distribution circuit (5 of 6) -> HANDSFREE ACCESS POWER TAILGATE CLOSE SWITCH
