Acura MDX IV (2021-2024) front passenger's massage seat control unit Wiring diagrams
This page contains all the electrical diagrams for the component. front passenger's massage seat control unit, in which he is found in the car Acura MDX IV (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram front passenger's massage seat control unit (1 of 2)
BLK WIRE
BLU WIRE
CLIMATE CONTROL PANEL
COMPUTER DATA LINES SYSTEM
DRIVER'S MASSAGE SEAT AIR PUMP
DRIVER'S MASSAGE SEAT CONTROL UNIT
DRIVER'S MASSAGE SEAT IND
DRIVER'S MASSAGE SEAT SWITCH
DRIVER'S POWER SEAT CONTROL UNIT
FRONT PASSENGER'S MASSAGE SEAT AIR PUMP
FRONT PASSENGER'S MASSAGE SEAT CONTROL UNIT
FRONT PASSENGER'S MASSAGE SEAT IND
FRONT PASSENGER'S MASSAGE SEAT SWITCH
FRONT PASSENGER'S POWER SEAT CONTROL UNIT
FUSE 41
FUSE 43
FUSE 53
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/
PNK WIRE
RED WIRE
UNDER-DASH FUSE/RELAY BOX
WHT WIRE
YEL WIRE
Go to component -> Massage seats circuit -> FRONT PASSENGER'S MASSAGE SEAT CONTROL UNIT
Wiring diagram front passenger's massage seat control unit (2 of 2)
BLU WIRE
CAN GATEWAY
CIRCUIT BREAKER 13
DRIVER'S JUNCTION BOX B
DRIVER'S MASSAGE SEAT CONTROL UNIT
DRIVER'S POWER SEAT CONTROL UNIT
ELECTRONIC AIR SUSPENSION CONTROL UNIT
FROM FUSE HOLDER A (DIAGRAM 3 OF 12)
FRONT CONSOLE USB CHARGER UNIT
FRONT PASSENGER'S MASSAGE SEAT CONTROL UNIT
FRONT PASSENGER'S POWER SEAT CONTROL UNIT
FUSE 1
FUSE 10
FUSE 11
FUSE 12
FUSE 14
FUSE 2
FUSE 3
FUSE 32
FUSE 33
FUSE 35
FUSE 36
FUSE 38
FUSE 40
FUSE 41
FUSE 49
FUSE 5
FUSE 53
FUSE 54
FUSE 55
FUSE/RELAY HOLDER B
FUSE/RELAY HOLDER E
GRN WIRE
GRY WIRE
HANDSFREE POWER TAILGATE CLOSE SWITCH
LT BLU WIRE
N/A
PNK WIRE
POWER SUNSHADE MOTOR- CONTROL UNIT
POWER TAILGATE CONTROL UNIT
POWER TILT/ TELESCOPIC STEERING CONTROL UNIT
PPL
REAR CONSOLE USB CHARGER UNIT
REAR LIGHT JUNCTION UNIT
RED WIRE
SH-AWD CONTROL UNIT
SH-AWD RELAY
STEREO AMPLIFIER
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (9 of 12) -> FRONT PASSENGER'S MASSAGE SEAT CONTROL UNIT
