Acura MDX IV (2021-2024) front passenger's air bag active vent tether cutter Wiring diagram
This page shows the only wiring diagram for the component.front passenger's air bag active vent tether cutter, which is found in the car Acura MDX IV (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front passenger's air bag active vent tether cutter (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S JUNCTION BOX A
F-CAN H
F-CAN L
F-CAN TRANSCEIVER
FRONT PASSENGER'S AIR BAG ACTIVE VENT TETHER CUTTER
FRONT PASSENGER'S KNEE AIR BAG INFLATOR
FRONT PASSENGER'S SEAT BELT BUCKLE SWITCH
FRONT PASSENGER'S SEAT BELT TENSIONER
FUSE 20
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LEFT FRONT IMPACT SENSOR
LEFT REAR SEAT BELT TENSIONER
LEFT SIDE IMPACT PRESSURE SENSOR
LT BLU WIRE
LT GRN WIRE
PNK WIRE
RED WIRE
RIGHT SIDE IMPACT PRESSURE SENSOR
SEAT BELT REMINDER INDICATOR (LED)
SRS INDICATOR (LED)
TAN WIRE
UNDER-HOOD FUSE/RELAY BOX
WHT WIRE
Go to component -> Supplemental restraints circuit (2 of 3) -> FRONT PASSENGER'S AIR BAG ACTIVE VENT TETHER CUTTER
