Acura MDX IV (2021-2024) front parking/ daytime running light Wiring diagram
This page shows the only wiring diagram for the component.front parking/ daytime running light, which is found in the car Acura MDX IV (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front parking/ daytime running light (1 of 1)
3.0L TURBO
3.5L
B-CAN L B-CAN H
B-CAN TRANSCEIVER
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
FRONT PARKING/ DAYTIME RUNNING LIGHT
FRONT SIDE MARKER LIGHT
FRONT TURN SIGNAL LIGHT
FUSE CB
FUSE/RELAY HOLDER A
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HOT W/ DC-DC CONVERTER
LEFT POWER MIRROR
LEFT SIDE TURN SIGNAL LIGHT (LED)
LEFT TURN SIGNAL IND
LT GRN WIRE
PPL
RELAY ENERGIZED
RIGHT END OF DASH)
RIGHT HEADLIGHT
RIGHT POWER MIRROR
RIGHT SIDE TURN SIGNAL LIGHT (LED)
RIGHT TURN SIGNAL IND
VSA MODULATOR CONTROL UNIT
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (2 of 4) -> FRONT PARKING/ DAYTIME RUNNING LIGHT
