Acura MDX IV (2021-2024) driver's seat left bolster motor Wiring diagrams
This page contains all the electrical diagrams for the component. driver's seat left bolster motor, in which he is found in the car Acura MDX IV (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram driver's seat left bolster motor (1 of 2)
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S DOOR CONTROL UNIT
DRIVER'S SEAT LEFT BOLSTER MOTOR
DRIVER'S SEAT POWER THIGH SUPPORT MOTOR
DRIVER'S SEAT RIGHT BOLSTER MOTOR
DRIVING POSITION MEMORY SWITCH
FUSE 1
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
INDICATOR
LED
LIGHTS (LED)
LT BLU WIRE
LT GRN WIRE
PNK WIRE
POSITION
POSITION SENSOR
PPL
RED WIRE
SET-
TAN WIRE
UNDER-DASH FUSE/RELAY BOX
YEL WIRE
Go to component -> Driver"s memory seat circuit (2 of 3) -> DRIVER'S SEAT LEFT BOLSTER MOTOR
Wiring diagram driver's seat left bolster motor (2 of 2)
BLK WIRE
BRN WIRE
DRIVER'S BACK SEAT BLOWER MOTOR
DRIVER'S BACK SEAT HEATER
DRIVER'S POWER SEAT CONTROL UNIT
DRIVER'S SEAT BELT BUCKLE SWITCH
DRIVER'S SEAT CUSHION BLOWER MOTOR
DRIVER'S SEAT CUSHION HEATER
DRIVER'S SEAT HEIGHT MOTOR
DRIVER'S SEAT LEFT BOLSTER MOTOR
DRIVER'S SEAT POWER LUMBAR SUPPORT MOTOR A
DRIVER'S SEAT POWER LUMBAR SUPPORT MOTOR B
DRIVER'S SEAT POWER THIGH SUPPORT MOTOR
DRIVER'S SEAT RECLINE MOTOR
DRIVER'S SEAT RIGHT BOLSTER MOTOR
DRIVER'S SEAT SLIDE MOTOR
DRIVER'S SEAT TILT MOTOR
ELECTRONIC AIR SUSPENSION CONTROL UNIT
EPS CONTROL UNIT
FRONT PASSENGER'S POWER SEAT CONTROL UNIT
FRONT PASSENGER'S SEAT HEIGHT MOTOR
FRONT PASSENGER'S SEAT LEFT BOLSTER MOTOR
FRONT PASSENGER'S SEAT POWER LUMBAR SUPPORT MOTOR A
FRONT PASSENGER'S SEAT POWER LUMBAR SUPPORT MOTOR B
FRONT PASSENGER'S SEAT POWER THIGH SUPPORT MOTOR
FRONT PASSENGER'S SEAT RECLINE MOTOR
FRONT PASSENGER'S SEAT RIGHT BOLSTER MOTOR
FRONT PASSENGER'S SEAT SLIDE MOTOR
FRONT PASSENGER'S SEAT TILT MOTOR
FRONT SEAT HEATER CONTROL UNIT
FRONT SEAT HEATER CONTROL UNIT/VENTILATED SEAT CONTROL UNIT
FUEL TANK UNIT
LEFT REAR DOOR COURTESY LIGHT
LEFT REAR DOOR INNER HANDLE LIGHT
LEFT REAR DOOR LATCH
LEFT REAR DOOR LOWER AMBIENT LIGHT
LEFT REAR DOOR OUTER HANDLE
LEFT REAR DOOR POCKET LIGHT
LEFT REAR DOOR UPPER AMBIENT LIGHT
Go to component -> Ground distribution circuit (3 of 6) -> DRIVER'S SEAT LEFT BOLSTER MOTOR
