Acura MDX IV (2021-2024) driver's door lower ambient light Wiring diagrams
This page contains all the electrical diagrams for the component. driver's door lower ambient light, in which he is found in the car Acura MDX IV (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram driver's door lower ambient light (1 of 4)
3.0L TURBO
3.5L
BLU WIRE
DRIVER'S DOOR LOWER AMBIENT LIGHT
DRIVER'S DOOR UPPER AMBIENT LIGHT
DRIVER'S POWER SEAT CONTROL UNIT
FRONT PASSENGER'S DOOR INNER HANDLE LIGHT
FRONT PASSENGER'S POWER SEAT CONTROL UNIT
FRONT SEAT HEATER CONTROL UNIT/VENTILATED SEAT CONTROL UNIT
GRN WIRE
LEFT REAR DOOR INNER HANDLE LIGHT
LEFT REAR DOOR LOWER AMBIENT LIGHT
LEFT REAR DOOR POCKET LIGHT
LEFT REAR DOOR UPPER AMBIENT LIGHT
LEFT SIDE BSI RADAR UNIT
LT GRN WIRE
PNK WIRE
POWER TAILGATE CONTROL UNIT
RED WIRE
RIGHT REAR DOOR INNER HANDLE LIGHT
RIGHT REAR DOOR UPPER AMBIENT LIGHT
TAN WIRE
WHT WIRE
YEL WIRE
Go to component -> Computer data lines circuit (8 of 8) -> DRIVER'S DOOR LOWER AMBIENT LIGHT
Wiring diagram driver's door lower ambient light (2 of 4)
3.0L TURBO
3.5L
BLK WIRE
BLU WIRE
BODY CONTROL MODULE (LEFT SIDE OF DASH)
COMPUTER DATA LINES SYSTEM
DRIVER'S DOOR LATCH
DRIVER'S DOOR LOWER AMBIENT LIGHT
DRIVER'S DOOR POCKET LIGHT
DRIVER'S FOOTWELL LIGHT
DRIVER'S POWER TAILGATE SWITCH
DRIVING POSITION MEMORY SWITCH
ELECTRIC BRAKE BOOSTER
ELECTRIC SERVO BRAKE CONTROL UNIT/PEDAL FEEL SIMULATOR
FUSE 1
FUSE 2
FUSE 20
FUSE 29
FUSE 3
FUSE 4
FUSE 5-4
FUSE HOLDER A
GRN WIRE
HOT AT ALL TIMES
LT BLU WIRE
LT GRN WIRE
PNK WIRE
RED WIRE
RELAY CONTROL MODULE
RELAY ENERGIZED
TAN WIRE
UNDER-DASH FUSE/RELAY BOX
UNDER-HOOD FUSE/RELAY BOX
WHT WIRE
YEL WIRE
Go to component -> Courtesy lamps circuit (1 of 5) -> DRIVER'S DOOR LOWER AMBIENT LIGHT
Wiring diagram driver's door lower ambient light (3 of 4)
12 VOLT BATTERY SENSOR
AUTOMATIC LIGHTING/ RAIN SENSOR
BLK WIRE
BODY CONTROL MODULE
CARGO AREA ACCESSORY POWER SOCKET RELAY
DATA LINK CONNECTOR (DLC)
DC-DC CONVERTER ACC RELAY 1
DRIVER'S DOOR CONTROL UNIT
DRIVER'S DOOR COURTESY LIGHT
DRIVER'S DOOR INNER HANDLE LIGHT
DRIVER'S DOOR LATCH
DRIVER'S DOOR LOWER AMBIENT LIGHT
DRIVER'S DOOR OUTER HANDLE
DRIVER'S DOOR POCKET LIGHT
DRIVER'S DOOR UPPER AMBIENT LIGHT
DRIVER'S POWER TAILGATE SWITCH
DRIVER'S VANITY MIRROR LIGHT
DRIVING POSITION MEMORY SWITCH
ELECTRIC PARKING BRAKE SWITCH
FRONT CONSOLE ACCESSORY POWER SOCKET RELAY
FUEL PUMP CONTROL MODULE
FUEL PUMP DRIVER UNIT
FUSE/RELAY HOLDER A
FUSE/RELAY HOLDER E
HEATED STEERING WHEEL CONTROL UNIT
HIGH MOUNT BRAKE LIGHT
LEFT INNER TAILLIGHT
LEFT POWER MIRROR
LEFT REAR DOOR CONTROL UNIT
LICENSE PLATE LIGHT
MULTI VISOR SWITCH
MULTIPURPOSE CAMERA UNIT
PANORAMIC GLASS ROOF MOTOR-CONTROL UNIT
PASSENGER'S VANITY MIRROR LIGHT
POWER DOOR LOCK RELAY (DR UNLOCK)
POWER DOOR LOCK RELAY (LOCK)
POWER DOOR LOCK RELAY (UNLOCK)
POWER SUNSHADE MOTOR- CONTROL UNIT
POWER TAILGATE CONTROL UNIT
REAR VIEW MIRROR)
REAR WINDOW DEFOGGER
REAR WINDOW WIPER MOTOR
RIGHT INNER TAILLIGHT
ROOF MODULE)
UNDER-HOOD FUSE/RELAY BOX
USB CHARGING UNIT (LEFT THIRD ROW)
Go to component -> Ground distribution circuit (1 of 6) -> DRIVER'S DOOR LOWER AMBIENT LIGHT
Wiring diagram driver's door lower ambient light (4 of 4)
CENTER INSTRUMENT PANEL AMBIENT LIGHT
DRIVER'S DOOR INNER HANDLE LIGHT
DRIVER'S DOOR LOWER AMBIENT LIGHT
DRIVER'S DOOR POCKET LIGHT
DRIVER'S DOOR UPPER AMBIENT LIGHT
DRIVER'S FOOTWELL LIGHT
DRIVER'S INSTRUMENT PANEL AMBIENT LIGHT
FROM FUSE 22 (DIAGRAM 5 OF 12)
FRONT PASSENGER'S DOOR INNER HANDLE LIGHT
FRONT PASSENGER'S DOOR LOWER AMBIENT LIGHT
FRONT PASSENGER'S DOOR POCKET LIGHT
FRONT PASSENGER'S DOOR UPPER AMBIENT LIGHT
FRONT PASSENGER'S FOOTWELL LIGHT
FRONT PASSENGER'S INSTRUMENT PANEL AMBIENT LIGHT
FUSE 16
FUSE 20
FUSE 25
FUSE 26
LEFT CONSOLE BOX LIGHT
LEFT REAR DOOR INNER HANDLE LIGHT
LEFT REAR DOOR LOWER AMBIENT LIGHT
LEFT REAR DOOR POCKET LIGHT
LEFT REAR DOOR UPPER AMBIENT LIGHT
PANORAMIC GLASS ROOF MOTOR-CONTROL UNIT
PNK WIRE
PPL
RIGHT CONSOLE BOX LIGHT
RIGHT REAR DOOR INNER HANDLE LIGHT
RIGHT REAR DOOR LOWER AMBIENT LIGHT
RIGHT REAR DOOR POCKET LIGHT
RIGHT REAR DOOR UPPER AMBIENT LIGHT
SBW SHIFTER CONTROL MODULE
SRS UNIT
WHT WIRE
Go to component -> Power distribution circuit (7 of 12) -> DRIVER'S DOOR LOWER AMBIENT LIGHT
