Acura MDX IV (2021-2024) driver's back seat heater Wiring diagram
This page shows the only wiring diagram for the component.driver's back seat heater, which is found in the car Acura MDX IV (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver's back seat heater (1 of 1)
BLK WIRE
BRN WIRE
DRIVER'S BACK SEAT BLOWER MOTOR
DRIVER'S BACK SEAT HEATER
DRIVER'S POWER SEAT CONTROL UNIT
DRIVER'S SEAT BELT BUCKLE SWITCH
DRIVER'S SEAT CUSHION BLOWER MOTOR
DRIVER'S SEAT CUSHION HEATER
DRIVER'S SEAT HEIGHT MOTOR
DRIVER'S SEAT LEFT BOLSTER MOTOR
DRIVER'S SEAT POWER LUMBAR SUPPORT MOTOR A
DRIVER'S SEAT POWER LUMBAR SUPPORT MOTOR B
DRIVER'S SEAT POWER THIGH SUPPORT MOTOR
DRIVER'S SEAT RECLINE MOTOR
DRIVER'S SEAT RIGHT BOLSTER MOTOR
DRIVER'S SEAT SLIDE MOTOR
DRIVER'S SEAT TILT MOTOR
ELECTRONIC AIR SUSPENSION CONTROL UNIT
EPS CONTROL UNIT
FRONT PASSENGER'S POWER SEAT CONTROL UNIT
FRONT PASSENGER'S SEAT HEIGHT MOTOR
FRONT PASSENGER'S SEAT LEFT BOLSTER MOTOR
FRONT PASSENGER'S SEAT POWER LUMBAR SUPPORT MOTOR A
FRONT PASSENGER'S SEAT POWER LUMBAR SUPPORT MOTOR B
FRONT PASSENGER'S SEAT POWER THIGH SUPPORT MOTOR
FRONT PASSENGER'S SEAT RECLINE MOTOR
FRONT PASSENGER'S SEAT RIGHT BOLSTER MOTOR
FRONT PASSENGER'S SEAT SLIDE MOTOR
FRONT PASSENGER'S SEAT TILT MOTOR
FRONT SEAT HEATER CONTROL UNIT
FRONT SEAT HEATER CONTROL UNIT/VENTILATED SEAT CONTROL UNIT
FUEL TANK UNIT
LEFT REAR DOOR COURTESY LIGHT
LEFT REAR DOOR INNER HANDLE LIGHT
LEFT REAR DOOR LATCH
LEFT REAR DOOR LOWER AMBIENT LIGHT
LEFT REAR DOOR OUTER HANDLE
LEFT REAR DOOR POCKET LIGHT
LEFT REAR DOOR UPPER AMBIENT LIGHT
Go to component -> Ground distribution circuit (3 of 6) -> DRIVER'S BACK SEAT HEATER
