Acura MDX IV (2021-2024) canister change over valve Wiring diagram
This page shows the only wiring diagram for the component.canister change over valve, which is found in the car Acura MDX IV (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram canister change over valve (1 of 1)
A/C PRESSURE SENSOR
BLK WIRE
BLU WIRE
BRN WIRE
CANISTER CHANGE OVER VALVE
ECT SENSOR 2
EVAP CHECK MODULE PRESSURE SENSOR
EVAP LEAK CHECK MODULE
EVAP LEAK CHECK MODULE VACUUM PUMP
FUSE 38
FUSE 39
FUSE/ RELAY HOLDER F
GRN WIRE
GRY WIRE
LT BLU WIRE
LT GRN WIRE
PNK WIRE
PPL
PPL/BLK WIRE
PPL/RED WIRE
RED WIRE
TURBOCHARGER BOOST SENSOR
TURBOCHARGER BYPASS CONTROL SOLENOID VALVE
UNDER-HOOD FUSE/RELAY BOX
VTC OIL CONTROL SOLENOID VALVE B (BANK 2)
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 3.0l turbo (4 of 9) -> CANISTER CHANGE OVER VALVE
