Acura MDX IV (2021-2024) blu Wiring diagrams
This page contains all the electrical diagrams for the component. blu, in which he is found in the car Acura MDX IV (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram blu (132 of 158)
12 VOLT BATTERY SENSOR
3.0L TURBO
3.5L
3.5L AWD, 3.0L TURBO
AUDIO REMOTE- HFL SWITCH
BLU WIRE
BRN WIRE
CABLE REEL
DRIVER'S JUNCTION BOX B
ELECTRIC BRAKE BOOSTER
ELECTRIC SERVO BRAKE CONTROL UNIT/PEDAL FEEL SIMULATOR
ELECTRONIC AIR SUSPENSION CONTROL UNIT
GRN WIRE
HEATED STEERING WHEEL CONTROL UNIT
PNK WIRE
PPL
REAR DIFFERENTIAL PUMP MOTOR
RED WIRE
SRS UNIT (UNDER FRONT OF CENTER CONSOLE)
STEERING COLUMN)
VSA MODULATOR CONTROL UNIT
WHT WIRE
YEL WIRE
Go to component -> Computer data lines circuit (5 of 8) -> BLU WIRE
Wiring diagram blu (133 of 158)
3.5L AWD
AUTOMATIC LIGHTING CONTROL UNIT-SENSOR
BLU WIRE
CLIMATE CONTROL UNIT
DRIVER'S DOOR CONTROL UNIT
EXCEPT 3.5L AWD
FRONT PASSENGER'S DOOR CONTROL UNIT
GRY WIRE
LEFT REAR DOOR CONTROL UNIT
MASTER LIGHTING CONTROL UNIT
PANORAMIC GLASS ROOF MOTOR-CONTROL UNIT
PNK WIRE
POWER WINDOW MASTER SWITCH
RIGHT REAR DOOR CONTROL UNIT
RIGHT SIDE BSI RADAR UNIT
SECOND ROW SEAT HEATER CONTROL UNIT
UNDER-HOOD FUSE/RELAY BOX RELAY CONTROL MODULE
WHT WIRE
YEL WIRE
Go to component -> Computer data lines circuit (6 of 8) -> BLU WIRE
Wiring diagram blu (134 of 158)
0) OFF 1) PARK 2) AUTO 3) HEAD
BLK WIRE
BLU WIRE
BODY CONTROL MODULE
BRN WIRE
COMBINATION LIGHT SWITCH
COMPUTER DATA LINES SYSTEM
DRIVER'S JUNCTION BOX A
FRONT PARKING/ DAYTIME RUNNING LIGHT (LED)
FRONT SIDE MARKER LIGHT (LED)
FRONT TURN SIGNAL LIGHT (LED)
FUSE 20
FUSE 43
FUSE 5-5
FUSE HOLDER A
GRN WIRE
GRY WIRE
HAZARD WARNING SWITCH/FRONT PASSENGER'S AIR BAG CUT-OFF INDICATOR
HEADLIGHT SWITCH
HOT AT ALL TIMES
HOT W/
LEFT
LEFT HEADLIGHT
LT BLU WIRE
LT GRN WIRE
PASSENGER'S CENTER JUNCTION BOX D
PNK WIRE
PPL
RED WIRE
RELAY CONTROL MODULE
RIGHT
TURN SIGNAL SWITCH
UNDER-DASH FUSE/RELAY BOX
UNDER-HOOD FUSE/RELAY BOX
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (1 of 4) -> BLU WIRE
Wiring diagram blu (135 of 158)
3.0L TURBO
3.5L
B-CAN L B-CAN H
B-CAN TRANSCEIVER
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
FRONT PARKING/ DAYTIME RUNNING LIGHT
FRONT SIDE MARKER LIGHT
FRONT TURN SIGNAL LIGHT
FUSE CB
FUSE/RELAY HOLDER A
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HOT W/ DC-DC CONVERTER
LEFT POWER MIRROR
LEFT SIDE TURN SIGNAL LIGHT (LED)
LEFT TURN SIGNAL IND
LT GRN WIRE
PPL
RELAY ENERGIZED
RIGHT END OF DASH)
RIGHT HEADLIGHT
RIGHT POWER MIRROR
RIGHT SIDE TURN SIGNAL LIGHT (LED)
RIGHT TURN SIGNAL IND
VSA MODULATOR CONTROL UNIT
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (2 of 4) -> BLU WIRE
Wiring diagram blu (136 of 158)
BACKUP LAMPS CIRCUIT
BACKUP LIGHT (LED)
BLK WIRE
BLU WIRE
BRAKE LIGHT (LED)
BRN WIRE
CIRCUIT BREAKER 13
CIRCUIT BREAKER 15
CIRCUIT BREAKER 21
CIRCUIT BREAKER 26
FUSE 14
FUSE/RELAY HOLDER B
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LEFT INNER TAILLIGHT
LEFT TAILLIGHT
LICENSE PLATE LIGHT
LICENSE PLATE LIGHT (LED)
LT BLU WIRE
LT GRN WIRE
N/A
PNK WIRE
PPL
REAR LIGHT JUNCTION UNIT
REAR TURN LIGHT (LED)
RED WIRE
TAILLIGHT LIGHT (LED)
TAILLIGHT/REAR SIDE MARKER LIGHT (LED)
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (3 of 4) -> BLU WIRE
Wiring diagram blu (137 of 158)
BLK WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S JUNCTION BOX A
DRIVER'S JUNCTION BOX B
F-CAN H
F-CAN L
F-CAN TRANSCEIVER
FUSE 20
FUSE A
FUSE HOLDER A
FUSE/RELAY HOLDER A
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HEAD-UP DISPLAY (LEFT DASH)
HOT AT ALL TIMES
HOT W/ DC-DC CONVERTER
ILL DOWN
ILL UP
LT GRN WIRE
MULTI VISOR SWITCH
NCA WIRE
PNK WIRE
RED WIRE
TAN WIRE
TILT DOWN
TILT UP
UNDER-HOOD FUSE/RELAY BOX
Go to component -> Head-up display circuit -> BLU WIRE
Wiring diagram blu (138 of 158)
ABS IND.
AUTOMATIC BRAKE HOLD IND
B-CAN H
B-CAN L
B-CAN TRANSCEIVER
BLK WIRE
BLU WIRE
BRAKE HOLD SWITCH
BRAKE SYSTEM IND (AMBER)
BRAKE SYSTEM IND (RED) WIRE
BRN WIRE
BUZZER
CHARGING SYSTEM IND
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL SYSTEM
DOOR, TAILGATE OPEN IND
DRIVER'S JUNCTION BOX B
EPS IND
F-CAN H
F-CAN L
F-CAN TRANSCEIVER
FRONT FOG LIGHT IND
FUSE A
FUSE/RELAY HOLDER A
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HEAD-UP DISPLAY CIRCUIT
HIGH BEAM IND
HOT W/ DC-DC CONVERTER
IDLE STOP OFF SWITCH
IDLE STOP OFF/AUTOMATIC BRAKE HOLD SWITCH
ILLUM
INTEGRATED DYNAMICS SYSTEM SWITCH
KEYLESS ACCESS IND
LEFT TURN SIGNAL IND
LIGHTS ON IND
LOW TIRE PRESSURE/TPMS IND
LT BLU WIRE
LT GRN WIRE
MALFUNCTION IND LAMP (MIL)
MOST
MULTI VISOR SWITCH
MULTI-INFORMATION DISPLAY (MID)
NCA WIRE
PNK WIRE
PPL
RED WIRE
RIGHT TURN SIGNAL IND
SAFETY SUPPORT
SEAT BELT REMINDER IND
SECURITY IND
SOUND SYSTEMS
SRS IND
TAN WIRE
TRANSCEIVER/
VSA IND
VSA OFF
VSA OFF IND
WHT WIRE
WIPER/WASHER SYSTEM
YEL WIRE
Go to component -> Instrument cluster circuit (1 of 3) -> BLU WIRE
Wiring diagram blu (139 of 158)
3.0L TURBO
3.5L
BLK WIRE
BLU WIRE
BRAKE FLUID LEVEL SWITCH
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S DOOR LATCH
DRIVER'S DOOR SWITCH
ELECTRIC BRAKE BOOSTER
ELECTRIC SERVO BRAKE CONTROL UNIT/PEDAL FEEL SIMULATOR
FRONT PASSENGER'S DOOR LATCH
FRONT PASSENGER'S DOOR SWITCH
FUEL TANK UNIT
FULL LATCH SWITCH
FUSE 11
FUSE 23
FUSE HOLDER A
GRY WIRE
HOT AT ALL TIMES
LEFT REAR DOOR LATCH
LEFT REAR DOOR SWITCH
LT BLU WIRE
LT GRN WIRE
PNK WIRE
POWER TAILGATE CLOSER UNIT
POWER TAILGATE CONTROL UNIT
RELAY ENERGIZED
RIGHT END OF DASH)
RIGHT REAR DOOR LATCH
RIGHT REAR DOOR SWITCH
UNDER-DASH FUSE/RELAY BOX
UNDER-HOOD FUSE/RELAY BOX
WHT WIRE
YEL WIRE
Go to component -> Instrument cluster circuit (2 of 3) -> BLU WIRE
Wiring diagram blu (140 of 158)
BLK WIRE
BLU WIRE
BRN WIRE
CMP SENSOR A (BANK 1)
CMP SENSOR A (BANK 2)
CMP SENSOR B (BANK 1)
CMP SENSOR B (BANK 2)
EVAP CANISTER PURGE VALVE
FUEL RAIL PRESSURE SENSOR
GRN WIRE
GRY WIRE
LT BLU WIRE
LT GRN WIRE
MAP SENSOR
PCM
PNK WIRE
PPL
PPL/BLU WIRE
PPL/TAN WIRE
RED WIRE
ROCKER ARM OIL CONTROL SOLENOID
ROCKER ARM OIL PRESSURE SENSOR
TAN WIRE
THROTTLE ACTUATOR
THROTTLE OPEN SENSOR
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 3.0l turbo (9 of 9) -> BLU WIRE
