Car Wiring Diagrams for Rear wiper/washer circuit for Acura MDX III facelift (2015-2016)

AUXILIARY UNDER-DASH FUSE/RELAY BOX B-CAN H B-CAN L B-CAN TRANSCEIVER BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DIODE A DIODE B DRIVER'S UNDER-DASH FUSE/RELAY BOX FUSE 11 FUSE 12 FUSE 7 GAUGE CONTROL MODULE GRN WIRE HOT IN ON OR START HOT W/ DC-DC LT BLU WIRE LT GRN WIRE MICU PNK WIRE REAR FUSE/RELAY BOX REAR MICU REAR WINDOW WIPER RELAY RELAY ENERGIZED REVERSE RELAY TRANSMISSION CONTROL MODULE W/O AUTO IDLE STOP SYSTEM W/ AUTO IDLE STOP SYSTEM WHT WIRE WIP INT WIP INT WIP ON OFF WASH WASH WIP ON OFF WASH WASH WIPER/WASHER SWITCH

BLK WIRE BLU WIRE COMPUTER DATA LINES SYSTEM FUSE 31 FUSE 4 GRN WIRE HOT AT ALL TIMES HOT IN ON OR START LT BLU WIRE LT GRN WIRE PNK WIRE REAR WINDOW WASHER MOTOR RELAY REAR WINDOW WIPER MOTOR RED WIRE RELAY CONTROL MODULE UNDER-HOOD FUSE/RELAY BOX WINDSHIELD WASHER MOTOR RELAY WINDSHIELD WIPER CONTROL UNIT/MOTOR WINDSHIELD WIPER HIGH/LOW RELAY WINDSHIELD WIPER INTERMITTENT RELAY WINDSHIELD/REAR WINDOW WASHER MOTOR WIPER MOTOR RELAY YEL WIRE
