Ground distribution circuit for Acura MDX III facelift (2015-2016)

AC INVERTER UNIT ANC/ ACTIVE SOUND CONTROL UNIT BATTERY FAN MOTOR BATTERY SENSOR BLK WIRE BLU WIRE BRAKE FLUID LEVEL SWITCH CAN GATEWAY CENTER SWITCH PANEL/ INTERFACE DIAL CLIMATE CONTROL UNIT ENGINE ENGINE MOUNT CONTROL UNIT EPS CONTROL UNIT FRONT BLOWER MOTOR RELAY FRONT PASSENGER'S E-PRETENSIONER UNIT GRN WIRE HEADLIGHT LEVELING CONTROL UNIT HEATED WINDSHIELD WIPER AREA LEFT FOG LIGHT LEFT FRONT TURN SIGNAL/ PARKING LIGHT LEFT HEADLIGHT MILLIMETER WAVE RADAR UNIT MULTI VIEW CAMERA UNIT MULTIPURPOSE CAMERA UNIT SHIELD NAVIGATION DISPLAY UNIT POWER TRANSISTOR RADIATOR FAN MOTOR REAR BLOWER MOTOR RELAY REAR POWER TRANSISTOR RIGHT END OF DASH) RIGHT FOG LIGHT RIGHT FRONT TURN SIGNAL/ PARKING LIGHT RIGHT HEADLIGHT SBW SHIFTER CONTROL MODULE SECURITY HOOD SWITCH STEERING GEAR BOX TELEMATICS CONTROL UNIT/ HANDSFREELINK CONTROL UNIT TRANSMISSION HOUSING) VSA MODULATOR CONTROL UNIT WINDSHIELD WIPER CONTROL UNIT/MOTOR

AUXILIARY UNDER-DASH FUSE/RELAY BOX BLK WIRE BRN WIRE DATA LINK CONNECTOR (DLC) DC-DC CONVERTER DC-DC CONVERTER ACC RELAY DRIVER'S DOOR LOCK ACTUATOR/ KNOB SWITCH/ KEY CYLINDER SWITCH DRIVER'S DOOR OUTER HANDLE DRIVER'S POWER WINDOW MASTER SWITCH DRIVER'S POWER WINDOW MOTOR DRIVER'S UNDER-DASH FUSE/RELAY BOX DRIVING POSITION MEMORY SWITCH HIGH MOUNT BRAKE LIGHT KEYLESS ACCESS/ TPMS CONTROL UNIT KEYLESS BUZZER LEFT INNER BRAKE LIGHT/ INNER TAILLIGHT LEFT INNER TAILLIGHT LEFT LICENSE PLATE LIGHT LEFT POWER MIRROR MICU MULTI-PURPOSE CAMERA UNIT OPTION CONNECTOR (FOR TRAILER) POWER MIRROR CONTROL UNIT POWER MIRROR SWITCH POWER TAILGATE CONTROL UNIT POWER TILT/ TELESCOPIC STEERING CONTROL UNIT REAR DIFFERENTIAL PUMP MOTOR REAR WINDOW DEFOGGER REAR WINDOW WIPER MOTOR RIGHT INNER BRAKE LIGHT/ INNER TAILLIGHT RIGHT INNER TAILLIGHT RIGHT LICENSE PLATE LIGHT SH-AWD CONTROL UNIT TAILGATE LOCK SWITCH

BLK WIRE BRN WIRE CKP SENSOR CMP SENSOR DIODE D EGR VALVE/ EGR VALVE POSITION SENSOR FAN CONTROL RELAY GRY WIRE HEADLIGHT WASHER MOTOR HIGH PRESSURE FUEL PUMP SHIELD IGNITION COIL 1 IGNITION COIL 2 IGNITION COIL 3 IGNITION COIL 4 IGNITION COIL 5 IGNITION COIL 6 INJECTOR 1 SHIELD INJECTOR 2 SHIELD INJECTOR 3 SHIELD INJECTOR 4 SHIELD INJECTOR 5 SHIELD INJECTOR 6 SHIELD KNOCK SENSOR (BANK 1) SHIELD KNOCK SENSOR (BANK 2) SHIELD PCM RELAY CONTROL MODULE REAR WINDOW WASHER MOTOR RELAY ROCKER ARM OIL CONTROL SOLENOID A (BANK 1) ROCKER ARM OIL CONTROL SOLENOID A (BANK 2) ROCKER ARM OIL CONTROL SOLENOID B (BANK 1) ROCKER ARM OIL PRESSURE SWITCH A (BANK 1) ROCKER ARM OIL PRESSURE SWITCH A (BANK 2) SENSOR UNIT SHIELD TRANSMISSION CONTROL MODULE UNDER-HOOD FUSE/RELAY BOX WASHER FLUID LEVEL SWITCH WINDSHIELD WASHER MOTOR RELAY WINDSHIELD WIPER INTERMITTENT RELAY WIPER MOTOR RELAY

AUDIO UNIT/ AUDIO NAVIGATION UNIT AUTOMATIC DIMMING INSIDE MIRROR AUTOMATIC LIGHTING/ RAIN SENSOR BLK WIRE CABLE REEL CONSOLE ACCESSORY POWER SOCKET DATA LINK CONNECTOR (DLC) DRIVER'S DOOR POWER TAILGATE/ FUEL FILL DOOR OPENER SWITCH DRIVER'S POWER WINDOW MASTER SWITCH DRIVER'S UNDER-DASH FUSE/RELAY BOX DRIVER'S VANITY MIRROR LIGHT DVD PLAYER UNIT ELECTRICAL COMPASS UNIT EXCEPT CANADA FRONT ACCESSORY POWER SOCKET FRONT PASSENGER'S POWER WINDOW SWITCH GAUGE CONTROL MODULE HOMELINK UNIT LEFT BSI ALERT INDICATOR MICU MOONROOF CONTROL UNIT/ MOTOR OPTION CONNECTOR (FOR HEATED STEERING WHEEL) PASSENGER'S UNDER-DASH FUSE/RELAY BOX POWER TILT/ TELESCOPIC STEERING CONTROL UNIT ROOF CONSOLE MODULE SRS UNIT STEERING COLUMN) STEERING HEATER STEERING WHEEL HEATER RELAY STEREO AMPLIFIER W/ NAVIGATION W/O NAVIGATION

BLK WIRE BRN WIRE CABLE REEL CARGO AREA ACCESSORY POWER SOCKET CENTER ACCESSORY POWER SOCKET RELAY CMBS/ VSA OFF SWITCH CONSOLE BOX LIGHT CRUISE CONTROL COMBINATION SWITCH DASHLIGHTS BRIGHTNESS CONTROL SWITCH DRIVER'S E-PRETENSIONER UNIT FRONT ACCESSORY POWER SOCKET RELAY FRONT PASSENGER'S DOOR LOCK ACTUATOR/ KNOB SWITCH FRONT PASSENGER'S DOOR OUTER HANDLE FRONT SEAT HEATER RELAY FUEL FILL DOOR LOCK ACTUATOR FUEL PUMP CONTROL MODULE GAUGE CONTROL MODULE GLOVE BOX LIGHT HEADLIGHT WASHER SWITCH IDLE STOP OFF SWITCH INTEGRATED DYNAMICS SYSTEM SWITCH LEFT BRAKE LIGHT LEFT MIDDLE SEAT LOWER SWITCH LEFT MIDDLE SEAT UPPER SWITCH LEFT REAR DOOR LOCK ACTUATOR/ KNOB SWITCH LEFT REAR DOOR OUTER HANDLE LEFT REAR POWER WINDOW SWITCH LEFT REAR TURN SIGNAL LIGHT LEFT TAILLIGHT OPTION CONNECTOR (FOR BACKUP CONTROL) PADDLE SHIFTER + (UPSHIFT SWITCH) PADDLE SHIFTER - (DOWNSHIFT SWITCH) PARKING, BACKUP SENSOR CONTROL UNIT PASSENGER'S UNDER-DASH FUSE/RELAY BOX PASSENGER'S VANITY MIRROR LIGHT REAR ACCESSORY POWER SOCKET RELAY REAR CONTROLLER, SCREEN REAR FUSE/RELAY BOX REAR MICU REAR WINDOW WIPER RELAY RIGHT BSI ALERT INDICATOR RIGHT POWER MIRROR STEERING ANGLE SENSOR STEERING COLUMN) VSA OFF SWITCH W/ ACC, CMBS W/O ACC, CMBS WINDOW ANTENNA (AM/FM) SHIELD

BLK WIRE BLK/WHT WIRE BRN WIRE DRIVER'S POWER LUMBAR SUPPORT SWITCH DRIVER'S SEAT BELT BUCKLE SWITCH DRIVER'S SEAT CUSHION BLOWER MOTOR DRIVER'S SEAT CUSHION HEATER DRIVER'S SEAT POSITION SENSOR DRIVER'S SEAT- BACK HEATER DRIVER'S SEAT-BACK BLOWER MOTOR FRONT PASSENGER'S POWER LUMBAR SUPPORT SWITCH FRONT PASSENGER'S SEAT BACK HEATER FRONT PASSENGER'S SEAT BELT BUCKLE SWITCH FRONT PASSENGER'S SEAT CUSHION BLOWER MOTOR FRONT PASSENGER'S SEAT CUSHION HEATER FRONT PASSENGER'S SEAT-BACK BLOWER MOTOR FRONT PASSENGER'S WEIGHT SENSOR UNIT LEFT SECOND ROW SEAT ACTUATOR LEFT SECOND ROW SEAT BACK HEATER LEFT SECOND ROW SEAT CUSHION HEATER LEFT SIDE BSI RADAR UNIT POWER SEAT CONTROL UNIT POWER SEAT CONTROL UNIT/ ADJUSTMENT SWITCH REAR CLIMATE CONTROL PANEL REAR FUSE/RELAY BOX REAR MICU REAR SEAT HEATER CONTROL UNIT RIGHT BRAKE LIGHT RIGHT MIDDLE SEAT LOWER SWITCH RIGHT MIDDLE SEAT UPPER SWITCH RIGHT REAR DOOR LOCK ACTUATOR/ KNOB SWITCH RIGHT REAR DOOR OUTER HANDLE RIGHT REAR POWER WINDOW SWITCH RIGHT REAR TURN SIGNAL LIGHT RIGHT SECOND ROW SEAT ACTUATOR RIGHT SECOND ROW SEAT BACK HEATER RIGHT SECOND ROW SEAT CUSHION HEATER RIGHT SIDE BSI RADAR UNIT RIGHT TAILLIGHT SECOND SEAT HEATER RELAY VENTILATED SEAT CONTROL UNIT/ FRONT SEAT HEATER CONTROL UNIT W/ ACC
