Acura MDX III facelift (2015-2016) rear center lf antenna/ initiator Wiring diagrams
This page contains all the electrical diagrams for the component. rear center lf antenna/ initiator, in which he is found in the car Acura MDX III facelift (2015-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
rear center lf antenna/ initiator wiring diagram (1 of 2)
2-WAY TRANSCEIVER
BLK WIRE
BLU WIRE
BRN WIRE
DRIVER'S DOOR OUTER HANDLE
FRONT INTERIOR LF ANTENNA/ INITIATOR
FRONT PASSENGER'S DOOR OUTER HANDLE
GRN WIRE
GRY WIRE
KEYLESS ACCESS/ TPMS CONTROL UNIT
LEFT FRONT LF ANTENNA/ INITIATOR
LEFT REAR LF ANTENNA/ INITIATOR
LOCK SWITCH
LT BLU WIRE
LT GRN WIRE
NCA WIRE
OPTION CONNECTOR (FOR TRAILER)
ORG/ WIRE
PNK WIRE
PPL
REAR CENTER LF ANTENNA/ INITIATOR
RED WIRE
RIGHT FRONT LF ANTENNA/ INITIATOR
RIGHT REAR LF ANTENNA/INITIATOR
STEERING ANGLE SENSOR
TOUCH SENSOR
TRANSMISSION CONTROL MODULE
W/ ELECTRIC STEERING LOCK W/O ELECTRIC STEERING LOCK
WHT WIRE
XM ANTENNA
YEL WIRE
Go to component -> Anti-theft circuit (6 of 6) -> REAR CENTER LF ANTENNA/ INITIATOR
rear center lf antenna/ initiator wiring diagram (2 of 2)
2-WAY TRANSCEIVER
BLK WIRE
BLU WIRE
BRN WIRE
DRIVER'S DOOR OUTER HANDLE
FRONT INTERIOR LF ANTENNA/ INITIATOR
FRONT PASSENGER'S DOOR OUTER HANDLE
GRN WIRE
GRY WIRE
KEYLESS ACCESS/ TPMS CONTROL UNIT
LEFT FRONT LF ANTENNA/ INITIATOR
LEFT REAR LF ANTENNA/ INITIATOR
LOCK SWITCH
LT BLU WIRE
LT GRN WIRE
NCA WIRE
OPTION CONNECTOR (FOR TRAILER)
ORG/ WIRE
PNK WIRE
PPL
REAR CENTER LF ANTENNA/ INITIATOR
RED WIRE
RIGHT FRONT LF ANTENNA/ INITIATOR
RIGHT REAR LF ANTENNA/INITIATOR
STEERING ANGLE SENSOR
TOUCH SENSOR
TRANSMISSION CONTROL MODULE
W/ ELECTRIC STEERING LOCK W/O ELECTRIC STEERING LOCK
WHT WIRE
XM ANTENNA
YEL WIRE
Go to component -> Power door locks circuit (6 of 6) -> REAR CENTER LF ANTENNA/ INITIATOR
