Acura MDX III facelift (2015-2016) pnk Wiring diagrams
This page contains all the electrical diagrams for the component. pnk, in which he is found in the car Acura MDX III facelift (2015-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram pnk (81 of 120)
Go to component -> A/t circuit (1 of 2) -> PNK WIRE
Wiring diagram pnk (82 of 120)
Go to component -> Computer data lines circuit, w/ auto idle stop (1 of 5) -> PNK WIRE
Wiring diagram pnk (83 of 120)
Go to component -> Computer data lines circuit, w/ auto idle stop (2 of 5) -> PNK WIRE
Wiring diagram pnk (84 of 120)
Go to component -> Computer data lines circuit, w/o auto idle stop (1 of 4) -> PNK WIRE
Wiring diagram pnk (85 of 120)
Go to component -> Computer data lines circuit, w/o auto idle stop (3 of 4) -> PNK WIRE
Wiring diagram pnk (86 of 120)
Go to component -> Courtesy lamps circuit (2 of 3) -> PNK WIRE
Wiring diagram pnk (87 of 120)
Go to component -> Front heated seats circuit -> PNK WIRE
Wiring diagram pnk (88 of 120)
Go to component -> Front passenger power seat circuit -> PNK WIRE
Wiring diagram pnk (89 of 120)
Go to component -> Heated steering wheel circuit -> PNK WIRE
Wiring diagram pnk (90 of 120)
Go to component -> Rear heated seats circuit -> PNK WIRE
