Acura MDX III facelift (2015-2016) lt blu Wiring diagrams
This page contains all the electrical diagrams for the component. lt blu, in which he is found in the car Acura MDX III facelift (2015-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram lt blu (81 of 112)
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE 23
FUSE 3
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
KEYLESS ACCESS/ TPMS CONTROL UNIT
LT BLU WIRE
LT GRN WIRE
PNK WIRE
PPL
RED WIRE
RED/BLU WIRE
RELAY ENERGIZED
SENSOR UNIT (LEFT FRONT CORNER OF ENGINE COMPT)
TAN WIRE
TRANSMISSION CONTROL MODULE
UNDER-HOOD FUSE/RELAY BOX
WHT WIRE
YEL WIRE
Go to component -> A/t circuit (1 of 2) -> LT BLU WIRE
Wiring diagram lt blu (82 of 112)
32-BIT MICROCOMPUTER + FLASH ROM
AUXILIARY REAR RELAY BLOCK A
BLK WIRE
BLU WIRE
BRN WIRE
CAN L
CIRCUIT
COMPUTER DATA LINES SYSTEM
DISPLAY
DRIVE
DRIVER UNIT
DRIVER'S UNDER-DASH FUSE/RELAY BOX
F-CAN
FUSE 11
FUSE 14
FUSE 21
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/
INFORMATION
LEFT REAR DIFFERENTIAL FLUID PRESSURE SENSOR
LEFT REAR DIFFERENTIAL SOLENOID VALVE
LT BLU WIRE
MULTI-
PASSENGER'S UNDER-DASH FUSE/RELAY BOX
PCM
PRESSURE SENSOR
REAR DIFFERENTIAL FLUID TEMPERATURE SENSOR 1
REAR DIFFERENTIAL FLUID TEMPERATURE SENSOR 2
REAR DIFFERENTIAL PUMP MOTOR
REAR FUSE/ RELAY BOX
RED WIRE
RIGHT REAR DIFFERENTIAL FLUID PRESSURE SENSOR
RIGHT REAR DIFFERENTIAL SOLENOID VALVE
SH-AWD CONTROL UNIT
SH-AWD IND
SH-AWD RELAY
TAN WIRE
TFT
TRANSCEIVER/
WARNING
WHT WIRE
YEL WIRE
Go to component -> Awd circuit -> LT BLU WIRE
Wiring diagram lt blu (83 of 112)
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S DOOR SWITCH
DRIVER'S UNDER-DASH FUSE/RELAY BOX
DRIVER'S VANITY MIRROR LIGHT
FRONT PASSENGER'S DOOR SWITCH
FUSE 11
FUSE 30
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
INSTRUMENT ILLUMINATION CIRCUIT
INTERIOR LIGHT CUT RELAY
LEFT REAR INDIVIDUAL MAP LIGHT (LED)
LT BLU WIRE
MAP LIGHT SWITCH
MICU
OPTION CONNECTOR (FOR LEFT LED)
OPTION CONNECTOR (FOR RIGHT LED)
ORG/ WIRE
PASSENGER'S VANITY MIRROR LIGHT
PNK WIRE
PPL
RED WIRE
RELAY ENERGIZED
RIGHT END OF DASH)
RIGHT REAR INDIVIDUAL MAP LIGHT (LED)
TELEMATICS CONTROL UNIT/HANDSFREE LINK CONTROL UNIT
W/ NAVIGATION
WHT WIRE
YEL WIRE
Go to component -> Courtesy lamps circuit (1 of 3) -> LT BLU WIRE
Wiring diagram lt blu (84 of 112)
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DOOR
FUSE 13
GRN WIRE
GRY WIRE
ILLUM
INSTRUMENT ILLUMINATION CIRCUIT
LEFT CARGO AREA LIGHT
LEFT FRONT INDIVIDUAL MAP LIGHT
LEFT REAR DOOR SWITCH
LT BLU WIRE
MAP LIGHT SWITCH
ON OFF
ORG/ WIRE
PNK WIRE
POWER TAILGATE SWITCH
PPL
REAR FUSE/ RELAY BOX
REAR MICU
RED WIRE
RELAY ENERGIZED
RIGHT CARGO AREA LIGHT
RIGHT FRONT INDIVIDUAL MAP LIGHT
RIGHT REAR DOOR SWITCH
ROOF CONSOLE MODULE
WHT WIRE
WHT/PNK WIRE
YEL WIRE
Go to component -> Courtesy lamps circuit (2 of 3) -> LT BLU WIRE
Wiring diagram lt blu (85 of 112)
BLU WIRE
DRIVER'S FOOTWELL LIGHT
DRIVER'S JUNCTION BOX A
FRONT PASSENGER'S FOOTWELL LIGHT
GRN WIRE
GRY WIRE
LEFT MIDDLE SEAT LOWER SWITCH
LEFT MIDDLE SEAT UPPER SWITCH
LEFT REAR DOOR COURTESY LIGHT
LT BLU WIRE
RED WIRE
RIGHT MIDDLE SEAT LOWER SWITCH
RIGHT MIDDLE SEAT UPPER SWITCH
RIGHT REAR DOOR COURTESY LIGHT
W/ NAVIGATION
W/O NAVIGATION
WHT WIRE
Go to component -> Courtesy lamps circuit (3 of 3) -> LT BLU WIRE
Wiring diagram lt blu (86 of 112)
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
CONTROL BLOCK
COURTESY LAMP CIRCUIT
DOOR
DOOR LOCK KNOB
DRIVER'S DOOR KEY CYLINDER SWITCH
DRIVER'S DOOR LOCK ACTUATOR/ KNOB SWITCH/KEY CYLINDER SWITCH
DRIVER'S DOOR LOCK KNOB SWITCH
GRN WIRE
KEY
LEFT FRONT INDIVIDUAL MAP LIGHT
LEFT REAR DOOR COURTESY LIGHT
LT BLU WIRE
MAP LIGHT SWITCH
OFF ON
ORG/ WIRE
PNK WIRE
POWER TAILGATE CLOSER UNIT
POWER TAILGATE CONTROL UNIT
POWER WINDOW MASTER SWITCH
PPL
RED WIRE
RIGHT FRONT INDIVIDUAL MAP LIGHT
RIGHT REAR DOOR COURTESY LIGHT
ROOF CONSOLE MODULE
WHT WIRE
YEL WIRE
Go to component -> Entry light timer circuit (2 of 3) -> LT BLU WIRE
Wiring diagram lt blu (87 of 112)
Go to component -> Entry light timer circuit (3 of 3) -> LT BLU WIRE
Wiring diagram lt blu (88 of 112)
AUXILIARY UNDER-DASH FUSE/RELAY BOX
BLK WIRE
BLU WIRE
BRN WIRE
CENTER JUNCTION BOX
COMPUTER DATA LINES SYSTEM
DRIVER'S SEAT CUSHION BLOWER MOTOR
DRIVER'S SEAT CUSHION HEATER
DRIVER'S SEAT- BACK HEATER
DRIVER'S SEAT-BACK BLOWER MOTOR
DRIVER'S UNDER-DASH FUSE/RELAY BOX
FRONT PASSENGER'S SEAT BACK HEATER
FRONT PASSENGER'S SEAT CUSHION BLOWER MOTOR
FRONT PASSENGER'S SEAT CUSHION HEATER
FRONT PASSENGER'S SEAT-BACK BLOWER MOTOR
FRONT SEAT HEATER RELAY
FUSE 20
FUSE 26
FUSE 5
FUSE 7
GRN WIRE
HOT AT ALL TIMES
HOT IN ON OR START
HOT W/ DC-DC CONVERTER
LT BLU WIRE
LT GRN WIRE
MOTOR DRIVE IC
ORG/ WIRE
PASSENGER'S UNDER-DASH FUSE/RELAY BOX
PNK WIRE
PPL
RED WIRE
VENTILATED SEAT CONTROL UNIT/FRONT SEAT HEATER CONTROL UNIT
WHT WIRE
Go to component -> Front heated seats circuit -> LT BLU WIRE
Wiring diagram lt blu (89 of 112)
AUTO HEAD
AUTOMATIC LIGHTING/ RAIN SENSOR
BLK WIRE
BLU WIRE
BRN WIRE
COMBINATION LIGHT SWITCH
COMPUTER DATA LINES SYSTEM
DASH LIGHTS BRIGHTNESS CONTROL SWITCH
DIMMER/ FLASH-TO- PASS SWITCH
DRIVER'S UNDER-DASH FUSE/RELAY BOX
EXCEPT BASE
EXCEPT CANADA
FUSE 11
GRN WIRE
GRY WIRE
HAZARD WARNING SWITCH
HEADLIGHT SWITCH
LT BLU WIRE
MICU
NAVIGATION DISPLAY UNIT
OFF
OFF PARK
OPTIONAL CONNECTOR
PARK
PASS
PNK WIRE
RED WIRE
RELAY ENERGIZED
YEL WIRE
Go to component -> Instrument illumination circuit (3 of 4) -> LT BLU WIRE
Wiring diagram lt blu (90 of 112)
AUXILIARY UNDER-DASH FUSE/RELAY BOX
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S UNDER-DASH FUSE/RELAY BOX
FUSE 20
FUSE 26
FUSE 7
GRN WIRE
HOT AT ALL TIMES
HOT IN ON OR START
HOT W/ DC-DC CONVERTER
LEFT SECOND ROW SEAT BACK HEATER
LEFT SECOND ROW SEAT CUSHION HEATER
LT BLU WIRE
LT GRN WIRE
PASSENGER'S UNDER-DASH FUSE/RELAY BOX
PNK WIRE
PPL
REAR FUSE/RELAY BOX
REAR SEAT HEATER CONTROL UNIT
RED WIRE
RIGHT SECOND ROW SEAT BACK HEATER
RIGHT SECOND ROW SEAT CUSHION HEATER
SECOND SEAT HEATER RELAY
WHT WIRE
YEL WIRE
Go to component -> Rear heated seats circuit -> LT BLU WIRE
