Acura MDX III facelift (2015-2016) left inner brake light/ inner taillight Wiring diagram
This page shows the only wiring diagram for the component.left inner brake light/ inner taillight, which is found in the car Acura MDX III facelift (2015-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left inner brake light/ inner taillight (1 of 1)
AUXILIARY UNDER-DASH FUSE/RELAY BOX
BLK WIRE
BRN WIRE
DATA LINK CONNECTOR (DLC)
DC-DC CONVERTER
DC-DC CONVERTER ACC RELAY
DRIVER'S DOOR LOCK ACTUATOR/ KNOB SWITCH/ KEY CYLINDER SWITCH
DRIVER'S DOOR OUTER HANDLE
DRIVER'S POWER WINDOW MASTER SWITCH
DRIVER'S POWER WINDOW MOTOR
DRIVER'S UNDER-DASH FUSE/RELAY BOX
DRIVING POSITION MEMORY SWITCH
HIGH MOUNT BRAKE LIGHT
KEYLESS ACCESS/ TPMS CONTROL UNIT
KEYLESS BUZZER
LEFT INNER BRAKE LIGHT/ INNER TAILLIGHT
LEFT INNER TAILLIGHT
LEFT LICENSE PLATE LIGHT
LEFT POWER MIRROR
MICU
MULTI-PURPOSE CAMERA UNIT
OPTION CONNECTOR (FOR TRAILER)
POWER MIRROR CONTROL UNIT
POWER MIRROR SWITCH
POWER TAILGATE CONTROL UNIT
POWER TILT/ TELESCOPIC STEERING CONTROL UNIT
REAR DIFFERENTIAL PUMP MOTOR
REAR WINDOW DEFOGGER
REAR WINDOW WIPER MOTOR
RIGHT INNER BRAKE LIGHT/ INNER TAILLIGHT
RIGHT INNER TAILLIGHT
RIGHT LICENSE PLATE LIGHT
SH-AWD CONTROL UNIT
TAILGATE LOCK SWITCH
Go to component -> Ground distribution circuit (2 of 6) -> LEFT INNER BRAKE LIGHT/ INNER TAILLIGHT
