Acura MDX III facelift (2015-2016) half latch switch Wiring diagram
This page shows the only wiring diagram for the component.half latch switch, which is found in the car Acura MDX III facelift (2015-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram half latch switch (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
CLOSER MOTOR
DRIVER'S DOOR POWER TAILGATE/ FUEL FILL DOOR OPENER SWITCH
DRIVER'S POWER WINDOW MASTER SWITCH
DRIVER'S UNDER- DASH FUSE/ RELAY BOX
FULL LATCH SWITCH
GRN WIRE
GRY WIRE
HALF LATCH SWITCH
KEYLESS ACCESS/ TPMS CONTROL UNIT
LT BLU WIRE
LT GRN WIRE
MICU
NCA WIRE
NEUTRAL SWITCH
ORG/ WIRE
POWER SEAT CONTROL UNIT
POWER TAILGATE CLOSER UNIT (CENTER OF TAILGATE)
POWER TAILGATE SWITCH
RATCHET SWITCH
RED WIRE
RELEASE SWITCH
TAILGATE LATCH SWITCH
TRANSMISSION CONTROL MODULE
YEL WIRE
Go to component -> Power tailgate circuit (2 of 2) -> HALF LATCH SWITCH
