Acura MDX III facelift (2015-2016) front mode control motor Wiring diagram
This page shows the only wiring diagram for the component.front mode control motor, which is found in the car Acura MDX III facelift (2015-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front mode control motor (1 of 1)
A/C COMPRESSOR CLUTCH RELAY
A/C CONDENSER FAN RELAY
A/C DIODE A
BLK WIRE
BLU WIRE
BRN WIRE
CLIMATE CONTROL UNIT
DIODE C
DIODE D
DRIVER'S AIR MIX CONTROL MOTOR
FRONT MODE CONTROL MOTOR
FUSE 17
FUSE 28
FUSE 29
FUSE 30
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ PGM-FI MAIN RELAY 1 ENERGIZED
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PNK WIRE
PPL
RADIATOR FAN RELAY
REAR AIR MIX CONTROL MOTOR
REAR MODE CONTROL MOTOR
REAR WINDOW DEFOGGER RELAY
RED WIRE
UNDER-HOOD FUSE/RELAY BOX
WHT WIRE
YEL WIRE
Go to component -> Automatic a/c circuit (1 of 5) -> FRONT MODE CONTROL MOTOR
