Car Wiring Diagrams for Rear wiper/washer circuit for Acura MDX III facelift 2 (2016-2021)

32-BIT MICROCOMPUTER + FLASH ROM AUXILIARY UNDER-DASH FUSE/RELAY BOX B-CAN H B-CAN L B-CAN TRANSCEIVER BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DIODE A DIODE B DRIVER'S UNDER-DASH FUSE/RELAY BOX FUSE 11 FUSE 12 FUSE 7 GAUGE CONTROL MODULE GRN WIRE HOT IN ON OR START HOT W/ DC-DC LT GRN WIRE MICU PCM PNK WIRE REAR FUSE/RELAY BOX REAR MICU REAR WINDOW WIPER RELAY RED WIRE RELAY ENERGIZED REVERSE RELAY TAN WIRE TRANSMISSION CONTROL MODULE W/O AUTO IDLE STOP SYSTEM W/ AUTO IDLE STOP SYSTEM HYBRID EXCEPT HYBRID WHT WIRE WIP INT WIP INT WIP ON OFF WASH WASH WIP ON OFF WASH WASH WIPER/WASHER SWITCH

BLK WIRE BLU WIRE COMPUTER DATA LINES SYSTEM FUSE 31 FUSE 4 GRN WIRE HOT AT ALL TIMES HOT IN ON OR START HYBRID EXCEPT HYBRID LT BLU WIRE LT GRN WIRE PNK WIRE REAR WINDOW WASHER MOTOR RELAY REAR WINDOW WIPER MOTOR RED WIRE RELAY CONTROL MODULE UNDER-HOOD FUSE/RELAY BOX WINDSHIELD WASHER MOTOR RELAY WINDSHIELD WIPER HIGH/LOW RELAY WINDSHIELD WIPER INTERMITTENT RELAY WINDSHIELD WIPER MOTOR WINDSHIELD/REAR WINDOW WASHER MOTOR WIPER MOTOR RELAY YEL WIRE
