Car Wiring Diagrams for Power tailgate circuit, except hybrid for Acura MDX III facelift 2 (2016-2021)

BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM FUSE 1 FUSE 13 FUSE 16 FUSE 18 GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR START KEYLESS BUZZER LEFT POWER TAILGATE PINCH SENSOR LT GRN WIRE PNK WIRE POWER TAILGATE CONTROL UNIT POWER TAILGATE DRIVE UNIT (LEFT SIDE OF TAILGATE) POWER TAILGATE MOTOR POWER TAILGATE RELAY POWER TAILGATE SENSOR PPL REAR FUSE/RELAY BOX REAR MICU RED WIRE RIGHT POWER TAILGATE PINCH SENSOR TAN WIRE UNDER-HOOD FUSE/RELAY BOX W/O AUTO IDLE STOP SYSTEM W/ REAR SEAT ENTERTAINMENT, W/ AUTO IDLE STOP SYSTEM W/O AUTO IDLE STOP SYSTEM, REAR SEAT ENTERTAINMENT WHT WIRE YEL WIRE

BLK WIRE BLU WIRE BRN WIRE CLOSER MOTOR DRIVER'S POWER WINDOW MASTER SWITCH DRIVER'S UNDER- DASH FUSE/ RELAY BOX FUEL FILL DOOR OPENER SWITCH FULL LATCH SWITCH GRN WIRE GRY WIRE HALF LATCH SWITCH KEYLESS ACCESS/ TPMS CONTROL UNIT LT BLU WIRE LT GRN WIRE MICU NCA WIRE NEUTRAL SWITCH POWER SEAT CONTROL UNIT POWER TAILGATE CLOSER UNIT (CENTER OF TAILGATE) POWER TAILGATE SWITCH RATCHET SWITCH RED WIRE RELEASE SWITCH TAILGATE LATCH SWITCH TAN WIRE TRANSMISSION CONTROL MODULE W/ MVCS W/O MVCS YEL WIRE
