Acura MDX III facelift 2 (2016-2021) Computer data lines circuit, except hybrid w/o auto idle stop

BLK WIRE BLU WIRE BRN WIRE CAN GATEWAY DATA LINK CONNECTOR (DLC) DRIVER'S JUNCTION BOX A FUSE 16 FUSE 21 GRN WIRE GRY WIRE HEADLIGHT LEVELING CONTROL UNIT HOT AT ALL TIMES LT BLU WIRE PASSENGER'S UNDER-DASH FUSE/RELAY BOX PCM PNK WIRE PPL RELAY ENERGIZED SRS UNIT TAN WIRE UNDER-HOOD FUSE/RELAY BOX WHT WIRE YEL WIRE

BLU WIRE BRN WIRE CABLE REEL DRIVER'S JUNCTION BOX B ELECTRIC PARKING BRAKE CONTROL UNIT ENGINE MOUNT CONTROL UNIT GRY WIRE LT BLU WIRE MULTIPURPOSE CAMERA UNIT PNK WIRE PPL RIGHT END OF DASH) SBW SHIFTER CONTROL MODULE SH-AWD CONTROL UNIT STEERING ANGLE SENSOR STEERING COLUMN) STEERING COMMANDER SWITCH ASSEMBLY TAN WIRE VSA MODULATOR CONTROL UNIT W/ LDW WHT WIRE

AUDIO UNIT/ AUDIO NAVIGATION UNIT BATTERY FAN MOTOR BATTERY SENSOR BLK WIRE BLU WIRE BRN WIRE CLIMATE CONTROL UNIT DRIVER'S UNDER-DASH FUSE/RELAY BOX EPS CONTROL UNIT GAUGE CONTROL MODULE GRN WIRE GRY WIRE KEYLESS ACCESS/ TPMS CONTROL UNIT LT BLU WIRE PNK WIRE PPL TAN WIRE TELEMATICS CONTROL UNIT/ HANDSFREE LINK CONTROL UNIT TRANSMISSION CONTROL MODULE WHT WIRE

ANC/ACTIVE SOUND CONTROL UNIT BLU WIRE DRIVER'S JUNCTION BOX A DRIVER'S POWER WINDOW MASTER SWITCH DRIVER'S UNDER-DASH FUSE/RELAY BOX GRY WIRE LT BLU WIRE MICU OPTIONAL CONNECTOR ORG/ WIRE PARKING, BACKUP SENSOR CONTROL UNIT PASSENGER'S UNDER-DASH FUSE/RELAY BOX PNK WIRE POWER TAILGATE CONTROL UNIT PPL RELAY CONTROL MODULE TAN WIRE UNDER-HOOD FUSE/RELAY BOX YEL WIRE

AUTOMATIC LIGHTING/ RAIN SENSOR BLU WIRE LEFT SIDE BSI RADAR UNIT PNK WIRE POWER SEAT CONTROL UNIT REAR FUSE/ RELAY BOX REAR MICU REAR SEAT HEATER CONTROL UNIT RIGHT SIDE BSI RADAR UNIT TAN WIRE VENTILATED SEAT CONTROL UNIT/ FRONT SEAT HEATER CONTROL UNIT
