Acura MDX III facelift 2 (2016-2021) w/o auto idle stop system w/ auto idle stop system canada usa Wiring diagram
This page shows the only wiring diagram for the component.w/o auto idle stop system w/ auto idle stop system canada usa, which is found in the car Acura MDX III facelift 2 (2016-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/o auto idle stop system w/ auto idle stop system canada usa (1 of 1)
CANADA
CENTER JUNCTION BOX (UPPER RIGHT CENTER OF DASH)
CMBS OFF SWITCH
DRIVER'S DOOR INNER HANDLE LIGHT
DRIVER'S JUNCTION BOX A
ELECTRIC PARKING BRAKE/ AUTOMATIC BRAKE HOLD SWITCH
FRONT PASSENGER'S AIR BAG CUT-OFF INDICATOR
FRONT PASSENGER'S DOOR INNER HANDLE LIGHT
GRN WIRE
GRY WIRE
OPTION CONNECTOR (REAR PARKING, BACKUP SENSOR)
PARKING, BACKUP SENSOR SWITCH
PARKING, BACKUP SENSOR/ HEADLIGHT WASHER SWITCH
RED WIRE
ROOF CONSOLE MODULE
USA
W/O AUTO IDLE STOP SYSTEM W/ AUTO IDLE STOP SYSTEM CANADA USA
Go to component -> Instrument illumination circuit, except hybrid (2 of 4) -> W/O AUTO IDLE STOP SYSTEM W/ AUTO IDLE STOP SYSTEM CANADA USA
