Acura MDX III facelift 2 (2016-2021) w/ auto idle stop system except hybrid hybrid w/ mvcs w/o mvcs Wiring diagram
This page shows the only wiring diagram for the component.w/ auto idle stop system except hybrid hybrid w/ mvcs w/o mvcs, which is found in the car Acura MDX III facelift 2 (2016-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ auto idle stop system except hybrid hybrid w/ mvcs w/o mvcs (1 of 1)
0) OFF 1) PARK 2) AUTO 3) HEAD
20 PIN
20 PIN CONNECTOR
32 BIT MICROPROCESSOR, FLASH ROM
32-BIT MICROCOMPUTER + FLASH ROM
AUXILIARY UNDER-DASH FUSE/RELAY BOX
BLK WIRE
BLU WIRE
BRAKE PEDAL POSITION SWITCH
BRN WIRE
COMBINATION LIGHT SWITCH
COMPUTER DATA LINES SYSTEM
CONNECTOR
DRIVER'S JUNCTION BOX A
DRIVER'S UNDER-DASH FUSE/RELAY BOX
EXCEPT HYBRID
F-CAN H
F-CAN L
F-CAN TRANSCEIVER
FUSE 11
FUSE 7
GAUGE CONTROL MODULE
GRN WIRE
GRN/WHT WIRE
GRY WIRE
HEADLIGHT SWITCH
HOT W/ DC-DC
LEFT TURN SIGNAL IND
LT GRN WIRE
MICU
PCM
PNK WIRE
PPL
RED WIRE
RELAY ENERGIZED
RIGHT POWER MIRROR
RIGHT TURN SIGNAL IND
TAN WIRE
TURN SIGNAL SWITCH
W/ AUTO IDLE STOP SYSTEM EXCEPT HYBRID HYBRID W/ MVCS W/O MVCS
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (4 of 4) -> W/ AUTO IDLE STOP SYSTEM EXCEPT HYBRID HYBRID W/ MVCS W/O MVCS
