Acura MDX III facelift 2 (2016-2021) under-hood fuse/relay box Wiring diagrams

This page contains all the electrical diagrams for the component. under-hood fuse/relay box, in which he is found in the car Acura MDX III facelift 2 (2016-2021). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

under-hood fuse/relay box wiring diagram (1 of 91)

AUXILIARY UNDER-DASH FUSE/RELAY BOX BLK WIRE BLU WIRE BRN WIRE CAN GATEWAY DATA LINK CONNECTOR (DLC) DRIVER'S JUNCTION BOX A ENGINE MOUNT CONTROL UNIT FUSE 16 FUSE 5 GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ DC-DC CONVERTER KEYLESS ACCESS/ TPMS CONTROL UNIT LT BLU WIRE LT GRN WIRE PASSENGER'S UNDER-DASH FUSE/RELAY BOX PCM PNK WIRE PPL RELAY CONTROL MODULE RIGHT END OF DASH) SBW SHIFTER CONTROL MODULE TAN WIRE TRANSMISSION CONTROL MODULE UNDER-HOOD FUSE/RELAY BOX WHT WIRE YEL WIRE

Go to component -> Computer data lines circuit, except hybrid w/ auto idle stop (1 of 5) -> UNDER-HOOD FUSE/RELAY BOX

under-hood fuse/relay box wiring diagram (2 of 91)

BLK WIRE BLU WIRE BRN WIRE CAN GATEWAY DATA LINK CONNECTOR (DLC) DRIVER'S JUNCTION BOX A FUSE 16 FUSE 21 GRN WIRE GRY WIRE HEADLIGHT LEVELING CONTROL UNIT HOT AT ALL TIMES LT BLU WIRE PASSENGER'S UNDER-DASH FUSE/RELAY BOX PCM PNK WIRE PPL RELAY ENERGIZED SRS UNIT TAN WIRE UNDER-HOOD FUSE/RELAY BOX WHT WIRE YEL WIRE

Go to component -> Computer data lines circuit, except hybrid w/o auto idle stop (1 of 5) -> UNDER-HOOD FUSE/RELAY BOX

under-hood fuse/relay box wiring diagram (3 of 91)

ANC/ACTIVE SOUND CONTROL UNIT BLU WIRE DRIVER'S JUNCTION BOX A DRIVER'S POWER WINDOW MASTER SWITCH DRIVER'S UNDER-DASH FUSE/RELAY BOX GRY WIRE LT BLU WIRE MICU OPTIONAL CONNECTOR ORG/ WIRE PARKING, BACKUP SENSOR CONTROL UNIT PASSENGER'S UNDER-DASH FUSE/RELAY BOX PNK WIRE POWER TAILGATE CONTROL UNIT PPL RELAY CONTROL MODULE TAN WIRE UNDER-HOOD FUSE/RELAY BOX YEL WIRE

Go to component -> Computer data lines circuit, except hybrid w/o auto idle stop (4 of 5) -> UNDER-HOOD FUSE/RELAY BOX

under-hood fuse/relay box wiring diagram (4 of 91)

BLK WIRE BLU WIRE BRN WIRE CAN GATEWAY DATA LINK CONNECTOR (DLC) DRIVER'S JUNCTION BOX A FUSE 16 FUSE 21 GRN WIRE GRY WIRE HEADLIGHT LEVELING CONTROL UNIT HOT AT ALL TIMES LT BLU WIRE PASSENGER'S UNDER-DASH FUSE/RELAY BOX PCM PNK WIRE PPL RELAY ENERGIZED TAN WIRE UNDER-HOOD FUSE/RELAY BOX WHT WIRE YEL WIRE

Go to component -> Computer data lines circuit, hybrid (1 of 6) -> UNDER-HOOD FUSE/RELAY BOX

under-hood fuse/relay box wiring diagram (5 of 91)

BLU WIRE BRN WIRE DRIVER'S JUNCTION BOX A DRIVER'S JUNCTION BOX B DRIVER'S POWER WINDOW MASTER SWITCH DRIVER'S UNDER-DASH FUSE/RELAY BOX EPS CONTROL UNIT GAUGE CONTROL MODULE LT BLU WIRE MICU MULTI VIEW CAMERA UNIT OPTIONAL CONNECTOR ORG/ WIRE PARKING, BACKUP SENSOR CONTROL UNIT PASSENGER'S UNDER-DASH FUSE/RELAY BOX PNK WIRE POWER TAILGATE CONTROL UNIT PPL RED WIRE RELAY CONTROL MODULE TAN WIRE UNDER-HOOD FUSE/RELAY BOX WHT WIRE YEL WIRE

Go to component -> Computer data lines circuit, hybrid (5 of 6) -> UNDER-HOOD FUSE/RELAY BOX

under-hood fuse/relay box wiring diagram (6 of 91)

BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DRIVER'S JUNCTION BOX A DRIVER'S POWER WINDOW MASTER SWITCH DRIVING POSITION MEMORY SWITCH EXCEPT HYBRID FUSE 16 GRN WIRE GRY WIRE HOT AT ALL TIMES INDICATOR 1 INDICATOR 2 JOINT 1 (HYBRID) LT GRN WIRE ORG/ WIRE PNK WIRE POSITION 1 POSITION 2 POWER MIRROR CONTROL UNIT POWER MIRROR SWITCH POWER TILT/ TELESCOPIC STEERING CONTROL UNIT RED WIRE SET- UNDER-HOOD FUSE/RELAY BOX YEL WIRE

Go to component -> Driver"s memory seat circuit (2 of 2) -> UNDER-HOOD FUSE/RELAY BOX

under-hood fuse/relay box wiring diagram (7 of 91)

BLK WIRE BLU WIRE BRAKE LIGHT RELAY BRN WIRE COMPUTER DATA LINES SYSTEM ELECTRIC SERVO BRAKE CONTROL UNIT FUSE 3-8 FUSE 8 GRN WIRE GRY WIRE HALL SENSOR HOT AT ALL TIMES KEYLESS ACCESS/TPMS CONTROL UNIT LT BLU WIRE MAIN UNDER- HOOD FUSE BOX MOTOR OPTION CONNECTOR (TRAILER) OPTIONAL CONNECTOR PCM PNK WIRE PPL RED WIRE TAN WIRE TANDEM MOTOR CYLINDER (LEFT SIDE OF ENGINE COMPT) UNDER-HOOD FUSE/RELAY BOX WHT WIRE YEL WIRE

Go to component -> Electric servo brake system circuit (1 of 2) -> UNDER-HOOD FUSE/RELAY BOX

under-hood fuse/relay box wiring diagram (8 of 91)

32-BIT MICROCOMPUTER + FLASH ROM AUXILIARY UNDER-DASH FUSE/RELAY BOX B-CAN B-CAN H B-CAN L BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM CRUISE LIGHT DIMMING CIRCUIT DRIVER'S JUNCTION BOX A EXCEPT HYBRID FRONT FOG LIGHT IND FRONT FOG LIGHT RELAY FUSE 16 FUSE 18 FUSE 26 FUSE 27 FUSE 3-6 3-4 FUSE 7 GAUGE CONTROL MODULE GRN WIRE HEADLIGHT RELAY HIGH BEAM IND HOT AT ALL TIMES HOT W/ DC-DC LEFT FOG LIGHT LIGHTS ON IND MAIN UNDER- HOOD FUSE BOX OPTION CONNECTOR (FOR FOG LIGHT) PNK WIRE PPL RELAY ENERGIZED RIGHT FOG LIGHT TRANSCEIVER/ UNDER-HOOD FUSE/RELAY BOX W/O AUTO IDLE STOP SYSTEM W/ AUTO IDLE STOP SYSTEM EXCEPT HYBRID HYBRID WARNING DRIVER CIRCUIT WHT WIRE YEL WIRE

Go to component -> Headlamps circuit (2 of 3) -> UNDER-HOOD FUSE/RELAY BOX

under-hood fuse/relay box wiring diagram (9 of 91)

APP SENSOR APP SENSOR A APP SENSOR B AUXILIARY UNDER-DASH FUSE BOX BLK WIRE BRAKE PEDAL POSITION SWITCH BRN WIRE CENTER JUNCTION BOX COMPUTER DATA LINES SYSTEM DC-DC CONVERTER DRIVER'S UNDER-DASH FUSE/RELAY BOX FUSE 11 FUSE 2-6 FUSE 25 FUSE 3 FUSE 8 GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ LT BLU WIRE MAIN UNDER- HOOD FUSE BOX PCM PNK WIRE PPL RED WIRE SBW SHIFTER CONTROL MODULE UNDER-HOOD FUSE/RELAY BOX WHT WIRE YEL WIRE

Go to component -> Shift interlock circuit, except hybrid -> UNDER-HOOD FUSE/RELAY BOX

under-hood fuse/relay box wiring diagram (10 of 91)

APP SENSOR APP SENSOR A APP SENSOR B BLK WIRE BLU WIRE BRAKE PEDAL POSITION SWITCH BRN WIRE CENTER JUNCTION BOX COMPUTER DATA LINES SYSTEM DRIVER'S UNDER-DASH FUSE/RELAY BOX FUSE 11 FUSE 13 FUSE 25 FUSE 8 GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ HOT W/ ACC RELAY ENERGIZED KEYLESS ACCESS/TPMS CONTROL UNIT LT BLU WIRE LT GRN WIRE MAIN UNDER- HOOD FUSE BOX MICU PARK POSITION SENSOR PCM PNK WIRE PPL RED WIRE SBW SHIFTER CONTROL MODULE UNDER-HOOD FUSE/RELAY BOX WHT WIRE YEL WIRE

Go to component -> Shift interlock circuit, hybrid -> UNDER-HOOD FUSE/RELAY BOX
