Acura MDX III facelift 2 (2016-2021) twin motor unit oil pressure sensor Wiring diagram
This page shows the only wiring diagram for the component.twin motor unit oil pressure sensor, which is found in the car Acura MDX III facelift 2 (2016-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram twin motor unit oil pressure sensor (1 of 1)
A/C PRESSURE SENSOR
BLK WIRE
BLU WIRE
BRN WIRE
ECT SENSOR 2
EVAP CANISTER PURGE VALVE 2
FTP SENSOR
FUSE 8
GRN WIRE
HOT AT ALL TIMES
LT BLU WIRE
LT GRN WIRE
MAF/IAT SENSOR (IN AIR INTAKE DUCT)
MAIN UNDER- HOOD FUSE BOX
PNK WIRE
PPL
RED WIRE
TAN WIRE
TWIN MOTOR UNIT OIL PRESSURE SENSOR
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 3.0l hybrid, engine controls circuit (2 of 8) -> TWIN MOTOR UNIT OIL PRESSURE SENSOR
