Acura MDX III facelift 2 (2016-2021) transmission control module Wiring diagram
This page shows the only wiring diagram for the component.transmission control module, which is found in the car Acura MDX III facelift 2 (2016-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram transmission control module (21 of 21)
AUDIO UNIT/ AUDIO NAVIGATION UNIT
AUTOMATIC DIMMING INSIDE MIRROR
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DIODE A
DIODE B
DRIVER'S JUNCTION BOX A
DRIVER'S UNDER-DASH FUSE/RELAY BOX
EXCEPT HYBRID HYBRID
FUSE 11
LEFT BACKUP LIGHT
LT BLU WIRE
MICU
OPTIONAL CONNECTOR (FOR TRAILER) (REAR)
PCM
REAR FUSE/RELAY BOX
RELAY ENERGIZED
REVERSE RELAY
RIGHT BACKUP LIGHT
TRANSMISSION CONTROL MODULE
WHT WIRE
Go to component -> Backup lamps circuit -> TRANSMISSION CONTROL MODULE
