Acura MDX III facelift 2 (2016-2021) telematic control unit/ handsfree link control unit wiring diagram
This page shows the only wiring diagram for the component.telematic control unit/ handsfree link control unit, which is found in the car Acura MDX III facelift 2 (2016-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
telematic control unit/ handsfree link control unit wiring diagram (1 of 1)
BATTERY CONDITION MONITOR MODULE
BLK WIRE
BLU WIRE
BRN WIRE
CABLE REEL
COMPUTER DATA LINES SYSTEM
DRIVER'S AIR BAG INFLATOR
DRIVER'S JUNCTION BOX B (UPPER LEFT CENTER OF DASH)
DRIVER'S KNEE AIR BAG INFLATOR
FRONT PASSENGER'S AIR BAG CUT-OFF INDICATOR
FRONT PASSENGER'S AIR BAG INFLATOR
FUSE 19
FUSE 24
GRN WIRE
GRY WIRE
HYBRID EXCEPT HYBRID
INSIDE STEERING WHEEL)
LEFT FRONT IMPACT SENSOR
LT BLU WIRE
NCA WIRE
PASSENGER'S UNDER-DASH FUSE/RELAY BOX
PPL
RED WIRE
RELAY ENERGIZED
RIGHT FRONT IMPACT SENSOR
SRS UNIT
STEERING COLUMN)
TAN WIRE
TELEMATIC CONTROL UNIT (HYBRID)
TELEMATIC CONTROL UNIT/ HANDSFREE LINK CONTROL UNIT
WHT WIRE
YEL WIRE
Go to component -> Supplemental restraints circuit (1 of 3) -> TELEMATIC CONTROL UNIT/ HANDSFREE LINK CONTROL UNIT
